Intel SR2600URLXNA Spares Parts List & Configuration Manual page 21

UPC
FSRTCHSPR
901994
735858208086
FSR1600EESPR
901005
735858206600
FSR1625EESPR
901007
735858206631
FSR26XXEESPR
901995
735858208093
Combined chassis mechanical spare kit for
SR16xx and SR26xx systems. Includes:
•
Baffle for power supply-backplane area for
SR2600
•
Baffle for power supply-backplane area for
SR2625
•
1U and 2U CPU Ducts
•
PS Blank Filler
•
RMM3 Filler Panel
•
IO Module Filler Panel
•
Hard Drive Carriers (3.5" & 2.5")
•
SR26XX Non-redundant Fan Structure
•
Tape Drive Filler
•
CD tray w/Standoffs
•
Plastic Optical Drive guide + 2 screws
•
Optical Drive Filler Panel (3.5")
•
Die cast metal rack handles (set)
•
Seven Dimm Blanks
•
Misc Hardware (screws, thumbscrews, etc)
•
Processor Fan Bracket
•
SR1615 PS Air Baffle (/w Thumbscrew)
•
CD Tray w/o Standoffs
•
SR 1600 PS baffle
SR1600 Electrical spare kit. Includes:
• Bridge Board
• HS SKU Front panel board
• Fixed SKU front panel board
• Fan distribution board
• 1U riser (FSR16XXRISER)
• HS SKU50 pin front panel cable
• HS SKU USB front panel cable
• Fixed SKU front panel cable
• Fixed SKU USB front panel cable
• 2 SATA cabled for fixed HDDs
• Fixed SKU fan control cable
• Two backplane thumb skrews
• One 56mm non-redundant fan
SR1625 Electrical spare kit. Includes
• Bridge Board
• 2.5" HSBP
• Mini front panel board
• 1U PCIe riser (FSR16XXRISER)
• Front panel cable
• USB front panel cable
• I2C cable
• SATA cable harness (6 cables)
• One 56mm fan with short cable
• One 56mm fan with long cable
• Power distribution board
SR2600 and SR2625 Electrical Spare Kit.
Includes following system components:
• Bridge Board
• 2.5" HSBP for SR2625
• 3.5: HSBP for SR2600
Quantity
1
1
1
1
21
