Key Optional accessories:
To enable redundant power supply feature – order additional
power supply ASR1625PS
To add SW Raid5 support – order AXXRAKSW5 key
To add HW raid functionality: need to install add-in PCI HW
Raid controller, which must be cabled to Passive Midplane
Alternatively, Passive Midplane may be replaced with Active
(FALSASMP2)
To add support for 8 SAS/SATA drives by add-in controller –
order additional 2.5" HDD drive carriers (available in 10 pack
FXX25HDDCAR).
To add Standard Control Panel - order ASR1625FP
*Note: Only one control panel (Mini, Standard, or Local) can be
used in a system at a time
*Note: Standard CP, LCP and two additional drives are
installed in the same bay, and can not be installed at the same
time
For complete list of accessories – please reference section 2
Same as above but with North American power cord
SR1625URNA
901132
NA
Intel Server System SR1625UR active configuration.
SR1625URSAS
Includes:
900987
•
735858206754
•
•
•
•
•
•
•
•
•
•
•
•
Key Optional Accessories:
To enable redundant power supply feature – order additional
power supply (ASR1625PS)
To upgrade to full-reatured HW RAID on Active Midplane2:
order Raid key (AXXRAKSAS2) , minidimm
(AXXMINIDIMM512). RAID cache battery backup is optional
(AXXRSBBU3).
To add support for 8 drives by SAS controller on Active
2 processor heatsinks
1 hot-swap and redundant capable high-efficient 650W
power supply.
2 chassis front handles in the box (ears)
Intel Server Board S5520UR
Intel Server Chassis SR1625
Mini control panel
6 2.5" HDD carriers (and filler in slots 7&8)
5 redundant non-hotswap fans
1 full height full length riser with PCI Express 2.0 x16
slot,
Active cable-less Midplane2 board with 8-port LSI
1078 SAS controller upgradeable to HW RAID mode
Backplane with proprietary cable-less connection to
Midplane, supporting 8 hot-swap SAS/SATA drives.
Bridge board
7 DIMM blanks
2 processor heatsinks
1 hot-swap and redundant capable high-efficient 650W
power supply
2 chassis front handles in the box (ears)
1
1
6
