2.

Spares and Accessories Order Codes

2.1

I/O Modules

Product Code
MM
UPC
AXX10GBIOMOD
900962
735858206525
AXX4GBIOMOD2 Quad port GbE I/O module, based on Intel 82576
901359 controller. RJ-45 connectors. Compatible with
735858206532 S5520UR and S5500WB boards only.
Single port QDR speed InfiniBand I/O Module.
AXXIBQDRIOMOD
CX4 powered connector. MT25408A0-FCC-QIS
902559
Controller.
735858212601
Compatible with S5520UR boards only.
Internal 4-port SAS module, based on LSI* 1064e
controller, with Embedded RAID support.
AXX4SASMOD
(primarily targeted at non-Iintel chassis)
900946
Compatible with S5520UR, S5500WB, S5520HC,
735858206372
S5520SC boards only. Not compatible with Intel
rack server chassis.
Internal 4-port SAS module, based on LSI* 1078e
controller. Provides 4 port full featured
SAS/SATA RAID 0,1,5, 6 and striping capability
AXXROMBSASMR
for spans 10, 50, 60. (primarily targeted at non-
901641
Intel chassis)
735858208017
Compatible with S5520UR, S5500WB, S5520HC,
S5520SC boards only. Not compatible with Intel
rack server chassis.
Description
10GbE I/O module Dual port CX4 connector,
based on Intel 82598 EB controller.
Compatible with S5520UR and S5500WB boards
only.
Minimum
Order
Quantity
1
1
1
1
1
11
