Same as above but with North American power cord
SR2600URBRPNA
901187
NA
Intel Server System SR2600UR in active-SAS configuration.
SR2600URLX
Includes:
900988
735858206778
Key Optional Accessories:
To enable power supply redundancy – order AXX750WPS
To upgrade to full-reatured HW RAID on Active Midplane2:
order Raid key (AXXRAKSAS2) , minidimm
(AXXMINIDIMM512). RAID cache battery backup is optional
(AXXRSBBU3).
To add PCI-X support – included riser must be replaced with
ASR26XXFHXR
To add support for 6
ASR2500SIXDRV
To add support for SATA Tape Drive – order ASR2500SATAPE
*NOTE: ASR2500SIXDRV and ASR2500SATAPE are installed
in the same bay and can not be installed at the same time.
For complete list of accessories – please reference section 2.
Same as above but with North American power cord
SR2600URLXNA
901131
NA
Integrated Intel Server System SR2600URSATA
SR2600URSATA
Includes:
904560
735858 212649
•
Intel Server Board S5520UR
•
Intel Server Chassis SR2600
•
Standard control panel
•
5 3.5" HDD carriers
•
6 redundant and hot-swap fans
•
Tape drive bay filler
•
1 active butterfly riser with 5 PCI Express 2.0 x8 wired
slots (1 full-height x16 connectors, 2 full-height x8
connector and 2 low-profile x8 connectors)
•
Active cable-less Midplane2 board with 8-port LSI
1078 SAS controller upgradeable to HW RAID mode
•
Backplane with proprietary cable-less connection to
Midplane, supporting up to 6 hot-swap SAS/SATA
drives.
•
Bridge board
•
7 DIMM blanks
•
2 processor heatsinks
•
1 hot-swap and redundant capable high-efficient 750W
power supply
•
2 chassis front handles in the box (ears)
th
hot-swap 3.5 inch drive – order
•
Intel Server Board S5520UR
•
Intel Server Chassis SR2600
•
Standard control panel
•
5 3.5" HDD carriers
•
6 redundant and hot-swap fans
•
Tape drive bay filler
•
1 active butterfly riser with 5 PCI Express 2.0 x8 wired
slots (1 full-height x16 connectors, 2 full-height x8
