Intel SC5400BASE Product Brief page 2

Chassis Specifications
Chassis
Configuration Base
Chassis Order Code SC5400BASE
1
SC5400BASENA
Spares Kit Order
Maintenance kit: ARIG2PMKIT
Code
Form Factor Pedestal or 5U rack
(Requires rack conversion kit ARIGRACK)
Intel® Server Board
Intel® Server Boards S5000PSL and S5000XVN
Support
Drive Bays
One toolless fixed drive bay for up to six fixed drives
Optional hot-swap / toolless drive bays available:
6-drive SAS/SATA
Hot-Swap Disk
Up to six hot-swap drive bays via the following hot-swap
Drive Bay: Order disk drive bay upgrade kits:
Code 6-drive SAS/SATA—AXX6DRV3G
6-drive SAS/SATA Expander—AXX6DRV3GEXP
System Cooling Includes two system fans plus one power-supply fan
Power Supply 670-watt PFC
Redundant Power Yes—via upgrade kit
Capable
Toolless Features Fixed hard drive install and removal
Fixed or hot swap drive bays
5.25 peripheral install and removal
Optional rack rails
Optional cable management arm
Dimensions
17.5" (445 mm) x 8.6" (218 mm) x 26.9" (683 mm)
(H x W x D)
Bezel Features Lockable, black with support for Intel® Local Control Panel:
AXXLCPPED
Front Connectors
2 x USB
1 x Serial
To build your system and get more details on server configurations from Intel visit: www.intel.com/go/serverconfigurator
For more details on the Intel® Server Chassis SC5400 please see: support.intel.com/support/motherboards/server/chassis/sc5400
For more information on how to make the Intel® Server Chassis SC5400 part of your server environment, please contact
an Intel® Channel Partner Program participant.
North American power cord included in order codes ending in NA, power cord not included in all other order codes.
1
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS,
INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY RELATING TO SALE AND/OR USE OF INTEL PRODUCTS, INCLUDING
LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT, OR OTHER INTELLECTUAL
PROPERTY RIGHT.
Intel, the Intel logo, Intel. Leap ahead., and the Intel. Leap ahead. logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States
and other countries.
Copyright © 2006 Intel Corporation. All rights reserved. 0806/MS/AT
Intel® Server Chassis SC5400
BRP
SC5400BRP
SC5400BRPNA
Maintenance kit: ARIG2PMKIT
Pedestal or 5U rack
(Requires rack conversion kit ARIGRACK)
Intel® Server Board S5000PSL
One toolless fixed drive bay for up to six fixed drives
Optional hot-swap / toolless drive bays available:
6-drive SAS/SATA, 4-drive SAS/SATA
Optional 4-drive toolless fixed drive bay
Up to ten hot-swap drive bays are possible with the
combination of the following drive bay upgrade kits:
6-drive SAS/SATA—AXX6DRV3G
6-drive SAS/SATA Expander—AXX6DRV3GEXP
4-drive SAS/SATA—AXX4DRV3G
4-drive SAS/SATA Expander—AXX4DRV3GEXP
Includes two system fans plus one power-supply fan
830-watt, dual-line cord, 1+1 PFC
Yes (fully redundant configuration requires second power
module FXX830WPSU)
Fixed hard drive install and removal
Fixed or hot swap drive bays
5.25 peripheral install and removal
Optional rack rails
Optional cable management arm
17.5" (445 mm) x 8.6" (218 mm) x 26.9" (683 mm)
Lockable, black with support for Intel® Local Control Panel:
AXXLCPPED
2 x USB
1 x Serial
nPlease Recycle 311919-002US
LX
SC5400LX
SC5400LXNA
Maintenance kit: ARIG2PMKIT
Pedestal or 5U rack
(Requires rack conversion kit ARIGRACK)
Intel® Server Board S5000PSL
One toolless fixed drive bay for up to six fixed drives
Optional hot-swap / toolless drive bays available:
6-drive SAS/SATA, 4-drive SAS/SATA
Optional 4-drive toolless fixed drive bay
Up to ten hot-swap drive bays are possible with the
combination of the following drive bay upgrade kits:
6-drive SAS/SATA—AXX6DRV3G
6-drive SAS/SATA Expander—AXX6DRV3GEXP
4-drive SAS/SATA—AXX4DRV3G
4-drive SAS/SATA Expander—AXX4DRV3GEXP
Supports redundant cooling with four high-flow system fans
plus up to two power-supply fans
830-watt, dual-line cord, 1+1 PFC
Yes (fully redundant configuration requires second power
module FXX830WPSU)
Fixed hard drive install and removal
Fixed or hot swap drive bays
5.25 peripheral install and removal
Cooling fans
Optional rack rails
Optional cable management arm
17.5" (445 mm) x 8.6" (218 mm) x 26.9" (683 mm)
Lockable, black with support for Intel® Local Control Panel:
AXXLCPPED
2 x USB
1 x Serial
