iBoard
READ INSTRUCTIONS CAREFULLY BEFORE
STARTING INSTALLATION. REMOVE CONTENTS
FROM BOX AND VERIFY ALL PARTS ARE PRE-
SENT. ASSISTANCE IS RECOMMENDED.
*ROCKER PANEL MOUNT
*DRILLING IS REQUIRED
PART LIST
Driver Front Mounting
Bracket (DFM)
Driver Front Support
Bracket (DFS)
Driver Rear Support
Bracket (DRS)
iBoard
by APS
Driver Rear Mounting
Bracket (DRM)
Customer Support: info@iboardauto.com
®
Fastener Size
Tightening Torque (ft-lbs)
6mm
8mm
10mm
12mm
14mm
Front
Passenger Front Mounting
Passenger Front Support
Passenger Rear Support
Passenger Rear Mounting
Bracket (PRM)
1
PART#: IB-R913
Required
6-7
16-18
31-32
56-58
92-94
Bracket (PFM)
Bracket (PFS)
Bracket (PRS)
Rev. 20220301
√
√
√
X
X
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for APS iBoard IB-R913
Summary of Contents for APS iBoard IB-R913
- Page 1 ® ® iBoard by APS PART#: IB-R913 Fastener Size Tightening Torque (ft-lbs) Required READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. REMOVE CONTENTS √ FROM BOX AND VERIFY ALL PARTS ARE PRE- 16-18 √ SENT. ASSISTANCE IS RECOMMENDED. 10mm 31-32 √...
- Page 2 iBoard ® Hardware Package A (For Bracket Installation) Item Description Item Description M10X1.5 J-Bolts M10 Hex Nuts M10X1.5-35mm Hex Bolts M8X1.25-20mm Hex Bolts M10 Large Flat Washers M8 Flat Washers M8 Nylon Lock Nuts M10 Lock Washers Hardware Package B (For Step Bar Installation) Item Description Item...
- Page 3 iBoard ® STEP 1 STEP 2 Starting from the driver front side of the vehicle. Install Assemble Driver Front Mounting Bracket (DFM) and Driver M10X1.5 J-Bolt in the large hole in the frame, (Figs 1-2). Front Support Bracket (DFS) with (2) M8X1.25-20mm Hex Note: Dodge Durango requires pinch weld holes used for in- Bolts, (4) M8 Flat Washers and (2) M8 Nylon Lock Nuts, (Fig stallation to be drilled out to 3/8”...
- Page 4 iBoard ® STEP 4 Enlarge These Holes With 3/8’’ Move to the driver rear side of the vehicle. Assemble Driver Drill Bit Rear Mounting Bracket (DRM) and Driver Rear Support Bracket (DRS) with (2) M8X1.25-20mm Hex Bolts, (4) M8 Flat Washers and (2) M8 Nylon Lock Nuts, (Fig 6).
- Page 5 iBoard ® M6X1-20mm Square Head Bolts For Dodge Durango A 3/8’’ Hole Must Be Added To The Pinch Weld (Fig 9) Slip M6X1-20mm Square Head Bolts Into The Bottom Channels Fig 7 (2) M6X1-20mm Square Head Bolts (2) M8x1.25-20mm Hex Bolts (2) M6 Large Flat Washers (4) M8 Flat Washers (2) M8 Nylon Lock Nuts...
