- Page 1 ADA-S9303 User Manual Document Revision: 1.0 18/12/2024...
- Page 2 ADA-S9303 User Manual V1.0 - 18/12/2024 © 2024 Copyright Alpha Data Parallel Systems Ltd. All rights reserved. This publication is protected by Copyright Law, with all rights reserved. No part of this publication may be reproduced, in any shape or form, without prior written consent from Alpha Data Parallel Systems Ltd.
-
Page 3: Table Of Contents
ADA-S9303 User Manual V1.0 - 18/12/2024 Table Of Contents Introduction ............................1 Key Features ..........................1 Main Input Power Supply Requirements ..................3 Installation and Power Up ....................... 3 JTAG Interface ..........................3 USB to UART Interface ........................3 Current/Voltage Monitoring ......................4 On-Board Generated Power Supplies .................... - Page 4 ADA-S9303 User Manual V1.0 - 18/12/2024 Page Intentionally left blank...
-
Page 5: Introduction
V1.0 - 18/12/2024 1 Introduction The ADA-S9303 is a stand-alone RFSoC enclosure providing 16-RF analogue channels, Ethernet, RS232 Serial COM, USB, QSFP and GPIO. The RF channels can run up to 10GSPS (DAC) and 5 GSPS(ADC) The ADA-S9303 uses a single 15V-24V input power supply. An on-board system monitor micro-controller provides voltage/current monitoring of the generated power supplies, as well as providing the capability to turn the supplies on/off via the micro USB interface. - Page 6 ADA-S9303 User Manual V1.0 - 18/12/2024 Figure 1 : ADA-S9303 ADMC-XMC-STANDALONE User Manual: https://www.alpha-data.com/xml//user_manuals/ adc-xmc-standalone%20user%20manual_v2_0.pdf ADM-XRC-9R1B User Manual: https://www.alpha-data.com/xml//user_manuals/ adm-xrc-9r1-b%20user%20manual_v1_1.pdf ADM-XRC-9R1B Reference Design: https://www.alpha-data.com/resource/admxrc9r1 Page 2 Introduction ad-ug-01515_ADA-S9303_User_Manual_v1_0.pdf...
-
Page 7: Main Input Power Supply Requirements
ADA-S9303 User Manual V1.0 - 18/12/2024 2 Main Input Power Supply Requirements The total power requirement will vary depending on the particular FPGA design. A 60W supply would likely be more than enough for most FPGA designs before thermal limits of the device and heatsink become the limiting factor. -
Page 8: Current/Voltage Monitoring
V1.0 - 18/12/2024 6 Current/Voltage Monitoring The ADA-S9303 provides current sense functionality on the 12V and combined 3V3 internal supplies. These values can be reported over the micro-USB interface, using the alpha-data "avr2util" utility. Avr2util for Windows and the associated USB driver can be downloaded here: https://support.alpha-data.com/pub/firmware/utilities/windows/... -
Page 9: Front-Panel I/O
ADA-S9303 User Manual V1.0 - 18/12/2024 8 Front-Panel I/O The front panel interface consists of 20 SMA connectors. These connectors support an external reference clock input and output, two GPIO pins, 8 DAC signals and 8 ADC signals. Figure 2 : Front Panel Pinout... -
Page 10: Qsfp Pinout
FPGA Bank 129 Lane Tx0/Rx0 Tx3/Rx3 Tx1/Rx1 Tx2/Rx2 Tx2/Rx2 Tx1/Rx1 Tx3/Rx3 Tx0/Rx0 Table 4 : ADM-XRC-9R1-B pcb pinout for J16 11 GPIO pinout The ADA-S9303 provides 8 GPIO (plus one ground pin) via its D-SUB connector. Page 6 GPIO pinout ad-ug-01515_ADA-S9303_User_Manual_v1_0.pdf... -
Page 11: Table 5 Gpio Pin Mapping
ADA-S9303 User Manual V1.0 - 18/12/2024 Figure 5 : GPIO DSUB Pin Numbers DSUB Pin Number FPGA Pin Number Voltage Standard 3.3V CMOS 3.3V CMOS 3.3V CMOS 3.3V CMOS N/A (GND) 3.3V CMOS 3.3V CMOS 3.3V CMOS 3.3V CMOS Table 5 : GPIO pin mapping... -
Page 12: Dimensions
ADA-S9303 User Manual V1.0 - 18/12/2024 12 Dimensions Dimension Measurement Width 275mm Depth 165mm Height 48mm Weight 1500g Table 6 : ADS-STANDALONE/9R1 dimensions 13 Order Code ADA-S9303/t/x/(f) Option Code Description blank = XMC (VITA 42) Connectors, XMC Connector type /V88 = XMC+ (VITA 88) Connectors... -
Page 13: Revision History
ADA-S9303 User Manual V1.0 - 18/12/2024 Revision History Date Revision Nature of Change First Release 18 Dec 2024 Address: Suite L4A, 160 Dundee Street, Address: 10822 West Toller Drive, Suite 250 Edinburgh, EH11 1DQ, UK Littleton, CO 80127 Telephone: +44 131 558 2600...
