A.8.4 Installation
Thermal camera module on UTC-115/120/124 Short side (only)

1.Take out the module from the package. Remove two screws on the peripheral cover.
2.Remove rear bottom I/O cover first
3.Remove the side cover, and open the small side door on the side cover.
4. Connect 2 USB cables to UTC.
5.Put side cover back, and notice 2 cables need to be came out through the hole on the side cover. Tighten the
peripheral with 2 screws.
6. Lock the peripheral cover with two screws
36
(Rear bottom I/O cover)
