Set and query the voltage current limit (Ilimit)
:ACPD:ILIMit A
Syntax
Command
:ACPD:ILIMit A
Query
:ACPD:ILIMit?
Response
A<NR2>
A = 0.1 to 100.0 [mA]
Details
Sets the current upper limit.
Returns the current upper limit.
Example
:ACPD:ILIMit 10.5
:ACPD:ILIMit?
(Response)10.5(When HEADER OFF)
