Blowers

Advertisement

12" PVC, 1 HP ECM
Speed
Optimum Airflow (CFM) and Static
(RPM)
1500 MAX
900 CFM @ 1.9" to 1025 CFM @ 1.8"
1400
900 CFM @ 1.8" to 1180 CFM @ 1.7"
1250
850 CFM @ 1.37" to 1325 CFM @ 0.8"
1000
675 CFM @ 0.9" to 1100 CFM @ 0.6"
750
450 CFM @ 0.45" to 825 CFM @ 0.33"
500
300 CFM @ 0.20" to 550 CFM @ 0.12"
300
200 CFM @ 0.08" to 400 CFM @ 0.10"
Pressure (inches of water)
0-10 vdc
Signal
9.0
8.3
7.4
6.0
4.4
2.9
1.8
76
4-20mA
Signal
20.0
18.8
16.9
13.9
10.9
7.9
5.5
