Labconco Spectrum 177050100 User Manual page 71

10" Coated Steel, 1 HP ECM
Speed (RPM)
1900 MAX
1750
1500
1250
1000
750
500
300
Optimum Airflow (CFM) and Static
Pressure (inches of water)
750 CFM @ 2.2" to 1000 CFM @ 2.0"
700 CFM @ 2.2" to 1050 CFM @ 1.8"
650 CFM @ 1.6" to 1250 CFM @ 0.7"
550 CFM @ 1.1" to 1050 CFM @ 0.5"
400 CFM @ 0.7" to 850 CFM @ 0.33"
275 CFM @ 0.37" to 650 CFM @ 0.20"
200 CFM @ 0.20" to 450 CFM @ 0.10"
175 CFM @ 0.06" to 350 CFM @ 0.08"
71
0-10 vdc 4-20mA
Signal Signal
9.0 19.9
8.2 18.5
7.1 16.2
6.0 13.9
4.9 11.7
3.7 9.4
2.6 7.1
1.7 5.3
