Data Log Rate
Data performance logs are stored in the Spectrum and are downloadable for
troubleshooting and monitoring purposes. The default is 10 seconds, which logs data
every 10 seconds. At a 10 second log rate, the Spectrum can store approximately 30
days of data at a time. After 30 days, the oldest log file will be deleted and rewritten with
the newest data. If using a 30 second log rate, the spectrum can store approximately 90
days of data. If the log rate is at the maximum 600 seconds (10 minutes), the storage
data wouldn't be rewritten for 1,800 days. To change the log rate, follow the instructions
below:
'LOG RATE' option in the menu, press [SELECT]. You will be prompted to
Locate the
choose the new rate increment. The available range is 10 seconds to 600 seconds in 10
second increments. Once the preferred rate option is found, press [SELECT]. The
screen will read 'SET TO X
Factory Reset
After making changes to the Spectrum Blower settings, the factory defaults can be
restored at any time. The default values for the Spectrum Blower can be seen in Table
7-1 in below.
To achieve a factory reset, scroll through the menu options and press
'FACTORY
you find
'CONFIRM RESET?' to return settings to the default values. Do this step in 30 seconds
or the display will return to the main menu.
Once the reset is completed, the blower will return to the main display and settings will
match Table 7-1.
Default Values
From the factory, the Spectrum Blower settings will be as stated in Table 7-1.
*Motor configuration is the only setting the factory reset will NOT change.
SEC' and return to the main display.
RESET'. User must press
Setting Description
Alarm Delay Time
Minimum RPM Alarm
Alarm Temperature
Data Log Rate
[SELECT] again when prompted
Default Value
60 Seconds
300 RPM
52°C
10 Seconds
41
[SELECT]
Table 7-1
