Settings
Motor Configuration
This programmed menu option must match the physical motor installed in the Spectrum
Blower.
Do not change the motor configuration setting of the Spectrum Blower unless it is
confirmed to be programmed differently from the physical configuration. See
Figure 7-2 to see the physical configuration of both the 1 HP motor and the 2 HP
motor without the weather cover installed.
DATA OUTPUT
MOTOR
Locate 'CONFIGURE' in the menu, press [SELECT]. You will be prompted to choose
the motor configuration between the two options
blower will return to the main display. Once the motor size is correctly shown, press
[SELECT].
If the motor configuration selected matches the previous setting, the display will read
'SET TO X HP' and return to the main display.
If the motor configuration selected does not match the previous setting, the display will
prompt 'CHANGE TO X
step must be done within 30 seconds, or the display will return to the main menu.
Once the motor configuration has been confirmed, the display will read
and return to the main display.
Alarms
There are three alarm settings that can be modified:
• Delay time of alarms
• Minimum RPM alarm
• Alarm temperature
RS-485
DATA OUTPUT
HP?'. Ensure the selection is correct and press [SELECT]. This
RS-232
DETAIL
'1 HP' and '2
39
Figure 7-2
DATA OUTPUT
MOTOR
HP'. Do this quickly or the
'SET TO X
HP'
