STWIN.box Modular platform expansion - STEVAL-C34KPM01

Hardware Overview

Power monitoring add-on

STWIN.box expansion with high precision current, voltage, power, and

temperature monitoring analog front-end (TSC1641)

• Total conversion time: 128µs to 32.768ms

• Load voltage sensing: 0 to 60V

• Load current sensing up to 10A

• 34-pin slave connector, compatible with STWIN.box and other ST

Evaluation boards

• 34-pin flex cable included

• Fixing holes
