ST STM32Cube Quick Start Manual page 38

• Once the connection is established,
you can:
•
Enable or disable the needed sensors.
•
Set up data rate, full scale, and timestamps.
•
Retrieve sensor status.
•
Load UCF to set up an MLC (machine
learning core) or an ISPU (intelligent sensor
processing unit).
•
Save and load a configuration via a JSON file.
•
Start or stop logging data on the PC.
• Once you click the "Start Log" button,
data are live plotted, and the
application creates a
YYYYMMDD_HH_MM_SS (e.g.,
20200128_16_33_00) folder
containing the raw data and the JSON
configuration file.
stdatalog_GUI.py
