Function pack for high speed datalogging and ultrasound processing

Hide thumbs Also See for STM32Cube:

STWIN.box Modular platform expansion - STEVAL-C34KAT1

Hardware Overview

Vibrometer and Temperature Sensors Expansion Board

STEVAL-C34AT01

STWIN.box expansion with Vibrometer (IIS3DWB) and Temperature

(STTS22H) sensors

• Optimal high frequency performance (up to 6kHz)

• Exposed pad on bottom side for thermal coupling

2.5cm

• 34-pin slave connector, compatible with STWIN.box and other ST

Evaluation boards

• 34-pin flex cable included

• 4x fixing holes

2.5cm

15cm

STEVAL-FLTCB01

Flex cable
