STEVAL-STWINBX1, STEVAL-STWINKT1B, and STEVAL-MKBOXPRO

can also be reprogrammed via USB using the STM32CubeProgrammer

in USB mode. To enter firmware upgrade mode, follow the procedure

below:

1. Unplug the core system board.

2. Press the USR button in STWIN and STWIN.box, or the DFU button

in SensorTile.box PRO.

3. While keeping the button pressed, connect the USB cable to the PC.

4. The board is now in DFU mode. Open STM32CubeProgrammer,

select the proper binary file, and download the firmware.

For further details, see UM2965 for STWIN.box, UM2777 for STWIN, or

UM3133 for SensorTile.box PRO

Firmware Update – USB
