  • Page 1 Installation, Operation & Maintenance Manual Four Post Surface Mounted Lift Model CL4P9HS (9,000 lb Capacity) 200 Cabel Street, P.O. Box 3944 Louisville, Kentucky 40201-3944 Email:sales@challengerlifts.com site:www.challengerlifts.com Office 800-648-5438 502-625-0700 Fax 502-587-1933 IMPORTANT: READ THIS MANUAL COMPLETELY BEFORE INSTALLING or OPERATING LIFT...
  • Page 2: General Specifications

    Model CL4P9HS Installation, Operation and Maintenance ENERAL PECIFICATIONS CL4P9HS SPECIFICATIONS 212½” [17’-8½”] Length Overall 112¼” Width Overall 95” Inside Columns 160½” [13’-4½”] Between Columns 84½” Height of Columns 5” Height of Runways 20” Width of Runways 37½” Width Between Runways 76”...
  • Page 3 Model CL4P9HS Installation, Operation and Maintenance Fig 2 – Drive Under Height Rev 8/18/09 Q4P09-IOM-A.doc...
  • Page 4: Vertical Clearance

    Model CL4P9HS Installation, Operation and Maintenance ERTICAL LEARANCE AFETY OTICES AND ECALS Check the height of the area where the lift is to be For your safety, and the safety of others, read and installed. Clearance should be calculated based on understand all of the safety notices and decals the full raised height of the lift.
  • Page 5: Installation

    IDLER COLUMN ASS’Y the shorted or damaged goods. Do this for your own protection. ENTRANCE RAMP NOTIFY Challenger Lifts, Inc. AT ONCE if any CROSS BEAM ASS’Y hidden loss or damage is discovered after receipt. POWER UNIT IT IS DIFFICULT TO COLLECT FOR LOSS OR...
  • Page 6 Model CL4P9HS Installation, Operation and Maintenance Fig 4 – Lock Clevis OLUMNS 4) Disassembly each column assembly place the columns close to each corner (column with the – Fig 6 Locking Ladder Orientation power unit bracket goes at the front left column per Fig 1).
  • Page 7 Model CL4P9HS Installation, Operation and Maintenance 10) Position runways on blocking (see Fig 9) per runway and cable #3 & #4 from the rear of the layout lines established in step 1. Use four 30” power runway, Fig 9. long 4x4’s spanning the width of the runway 11) Position the front and rear cross beams, and four 12”...
  • Page 8 Model CL4P9HS Installation, Operation and Maintenance PTIONAL 31) For installs on the front of the column (Fig NCHORING 13), rout the power unit supply line to the NOTE: Lift must be anchored in place if slope bulkhead shown below. Attach the 90 is grater then 1/8”...
  • Page 9 Model CL4P9HS Installation, Operation and Maintenance 37) B ERTAIN ITTINGS AND ONNECTIONS IGHT T IS THE INSTALLERS RESPONSIBILITY TO INSURE SYSTEM IS LEAK . Fill the Power Unit with three gallons of FREE clean 10wt anti-foam anti-rust hydraulic oil or Dexron III ATF.
  • Page 10: Wiring Diagram

    Model CL4P9HS Installation, Operation and Maintenance Wiring Diagram FOR SINGLE PHASE (Normally Open) FIELD CONECTIONS FOR THREE PHASE FACTORY WIRED FOR 208−240V RECONNECTIONS FOR 440−480V Fig 18 – WIRING DIAGRAM Rev 8/18/09 Q4P09-IOM-A.doc...
  • Page 11: Optional Accessories

    Model CL4P9HS Installation, Operation and Maintenance PTIONAL CCESSORIES (Q4P09CS) OBILITY (Q4P09DT) 1) This set of four casters when attached to the 1) Place drip tray between runways in the Jack cross beams of an unloaded lift, Fig 22, pick rail, Fig 19.
  • Page 12: Owner /Operator Checklist

    Model CL4P9HS Installation, Operation and Maintenance WNER PERATOR HECKLIST SAVE THESE INSTRUCTIONS deliver them to owner/user/employee along with other materials furnished with this lift. 45) Demonstrate the operation of the lift to the owner/operator and review correct and safe lifting procedures using the Lifting It Right booklet as a guide.
  • Page 13: Operation Procedure

    Model CL4P9HS Installation, Operation and Maintenance Automotive Lifts-Safety Requirements PERATION ROCEDURE Operation, Inspection and Maintenance. AFETY OTICES AND ECALS The Owner/Employer shall display the lift manufacturer’s operating instructions; ALI/SM This product is furnished with graphic safety 93 -1, ALI Lifting it Right safety manual; ALI/ST- warning labels, which are reproduced on 90 ALI Safety Tips card;...
  • Page 14: Lifting A Vehicle

    Model CL4P9HS Installation, Operation and Maintenance IFTING A EHICLE AINTENANCE Place entrance ramps in the slotted holes on the To avoid personal injury, permit only qualified front of the ramp. Drive vehicle onto lift. Set personnel to perform maintenance on this parking brake.
  • Page 15: Parts Breakdown

    IMPORTANT!!! Replace all worn or broken parts with genuine Challenger Lifts, Inc. parts. Contact your local Quality Lifts Parts Distributor for pricing and availability. (Call Challenger Lifts, Inc. (502) 625-0700 for the Parts Distributor in your area) Rev 8/18/09 Q4P09-IOM-A.doc...
  • Page 16 Model CL4P9HS Installation, Operation and Maintenance Parts Breakdown Fig A. General Layout Rev 8/18/09 Q4P09-IOM-A.doc...
  • Page 17 3/8-18 NPT x M14x1.5 90 DEGREE HYD. FITTING Replace all worn or broken parts with genuine Challenger Lifts Inc. parts. Contact your local Challenger Lifts Parts Distributor for pricing and availability. (Call Challenger Lifts Inc. (502) 625-0700 for the Parts Distributor in your area) Rev 8/18/09 Q4P09-IOM-A.doc...
  • Page 18 M22x2.5 NUT Replace all worn or broken parts with genuine Challenger Lifts Inc. parts. Contact your local Challenger Lifts Parts Distributor for pricing and availability. (Call Challenger Lifts Inc. (502) 625-0700 for the Parts Distributor in your area) Rev 8/18/09 Q4P09-IOM-A.doc...
  • Page 19 RUNWAY SHEAVE SPACER - SHORT Replace all worn or broken parts with genuine Challenger Lifts Inc. parts. Contact your local Challenger Lifts Parts Distributor for pricing and availability. (Call Challenger Lifts Inc. (502) 625-0700 for the Parts Distributor in your area) Rev 8/18/09 Q4P09-IOM-A.doc...
  • Page 20 Model CL4P9HS Installation, Operation and Maintenance PARTS BREAKDOWN (continued) Fig D. Cross Beams Rev 8/18/09 Q4P09-IOM-A.doc...
  • Page 21 Ø6mm x 30mm Lg. ROLL PIN Replace all worn or broken parts with genuine Challenger Lifts Inc. parts. Contact your local Challenger Lifts Parts Distributor for pricing and availability. (Call Challenger Lifts Inc. (502) 625-0700 for the Parts Distributor in your area) Rev 8/18/09 Q4P09-IOM-A.doc...
