7x12W ZOOM LED MINI MOVING HEAD
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
(ML-WZ007)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ML-WZ007 and is the answer not in the manual?

Questions and answers

Related Manuals for RIUKOE ML-WZ007

Summary of Contents for RIUKOE ML-WZ007

  • Page 1 7x12W ZOOM LED MINI MOVING HEAD (ML-WZ007) This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
  • Page 2 INDEX 1.STATEMENT ..................... 2.ACCESSORIES ..................3.SAFETY INSTRUCTION................4.INSTALLATION ..................5.CLAMP MOUNTING ................. 6.DMX CONNECTION ................. 7.TECHNICAL SPECIFICATION..............8.HOW TO SET THE UNIT ................9.CHANNEL DESCRIPTION ..............10.CLEANING AND MAINTENANCE ............

  • Page 3: Safety Instruction

    1.STATEMENT Thank you for choosing RIUKOE. The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included guarantee, also cannot responsible malfunction &...

  • Page 4: Preventing Electric Shock

    installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock Always power off/unplug the fixture before removing any covers. Ensure that the power is turned off when connecting the fixture to the AC mains supply.

  • Page 5: Installation

    Do not look directly at the light source from close range. Take precautions to prevent injury due to falls when working at height. For permanent installation, ensure that the fixture is securely fastened to a load-bearing surface with suitable corrosion-resistant hardware. For temporary installation with clamps, ensure that the quarter-turn fasteners are turned fully and secured with a suitable safety cable.

  • Page 6: Clamp Mounting

    5.CLAMP MOUNTING The LED moving head provides a unique mounting bracket assembly that integrates the bottom of the base, the included one unit (see the illustration below).When mounting this fixture to truss be sure to sere to secure an appropriately rated clamp to the included omega bracket using a M10 screw fitted through the center measure be sure to attached at least one properly rated safety cable to the fixture using on of the safety...

  • Page 7: Dmx-512 Connection With Dmx Terminator

    DMX-512 connection with DMX terminator: For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise.

  • Page 8: Dmx Address Setting

    DMX Address Setting: By using a universal DMX controller to control the units, you will need to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button up to when the DMX Address is showing on the display. Pressing the ENTER button and the display will blink.

  • Page 9: How To Set The Unit

    LED:7 PCS 12W high power RGBW LED DMX channel:16 channels Movement: Pan/Tilt: X axis540degree, Y axis 190degree Control mode:DMX512/Master-Slave/Auto run/sound Display: LED display 8 internal program , sound mode can control by DXM 512 WEIGHT&SIZE G.W: 5KG Packing size :34*27*24cm Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice.

  • Page 10: Function Mode

    5 Soun Sound Control .=OFF .=ON 6 PAN X Reverse .=OFF .=ON 7 TIL Y Reverse .=OFF .=ON 8 dISP Display Reverse .=OFF .=ON 9 rFAC Reset Default .=OFF .=ON HomePosition Clear PAN and TILT 10 Ad t Setting Delt HomePosition(3s) P(PAN) .=0-120...

  • Page 11: Channel Description

    The LED moving head have 16CH 8.2.3 Run Mode In the Run mode you can chose Master mode and Slave mode. 8.2.4 Auto Play With this function, you can run the 8 Inside program with master mode. 8.2.5 Sound [Music control]With this function, you can run sound-controlled. 8.2.6 Pan Reverse With this function you can reverse the Pan-movement.
  • Page 12 010 - 250 Strobe effect slow to fast 251 - 255 Strobe ( Open ) 000 - 255 ( 0 ~ 100% ) 000 - 255 Green ( 0 ~ 100% ) 000 - 255 Blue ( 0 ~ 100% ) 000 - 255 White ( 0 ~ 100% ) 000 - 255...

  • Page 13: Cleaning And Maintenance

    081 - 100 Internal program 4 101 - 120 Internal program 5 121 - 140 Internal program 6 141 - 160 Internal program 7 161 - 180 Internal program 8 181 - 200 Empty 201 - 225 Motor Reset 226 - 255 Empty 000-255 Focus (0-100%)
  • Page 14 Never use alcohol, solvents, or ammonia based cleaners. MAINTENANCE Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized service technician. Should you need any spare parts, please order genuine parts from your local dealer.
