RIUKOE ML-WZB740B User Manual

Mini 7x40w led bee eye moving head
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Mini 7x40W LED Bee Eye Moving Head
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
(ML-WZB740B)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ML-WZB740B and is the answer not in the manual?

Questions and answers

Related Manuals for RIUKOE ML-WZB740B

Summary of Contents for RIUKOE ML-WZB740B

  • Page 1 Mini 7x40W LED Bee Eye Moving Head (ML-WZB740B) This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.

  • Page 2: Table Of Contents

    INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.SAFETY INSTRUCTION................2 4.INSTALLATION ..................4 5.DMX CONNECTION ................. 5 6.TECHNICAL SPECIFICATION..............7 7.HOW TO SET THE UNIT ................9 8.CHANNEL DESCRIPTION ..............11 9.TROUBLE SHOOTING ................16 10.CLEANING AND MAINTENANCE ............17...

  • Page 3: Statement

    1.STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction & problem owing to ignore the manual.

  • Page 4: Preventing Electric Shock

    Review the following safety precautions carefully before installing or operating the fixture. This fixture must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock WARNING! Risk of electric shock.

  • Page 5: Avoid Personal Injury

    Avoid personal injury WARNING! Take measure to prevent personal injury. Do not look directly at the light source from close range.  Take precautions to prevent injury due to falls when working at height.  For permanent installation, ensure that the fixture is securely fastened to ...

  • Page 6: Dmx Connection

    mounting this fixture to truss be sure to sere to secure an appropriately rated clamp to the included Omega Bracket using a M10 screw fitted through the center hole of the ‘omega bracket’. As an added safety measure be sure to attached at least one properly rated Safety Cable to the fixture using one of the safety cable rigging point integrated in the base assembly.

  • Page 7: Dmx-512 Connection With Dmx Terminator

    DMX-512 connection with DMX terminator: For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain.

  • Page 8: Technical Specification

    functions without any change press the MENU button again. Press and hold the MENU button about one second or wait for about one minute to exit the menu mode. Please refer to the following diagram to address your DMX512 channel for the first 4 units： CHs Mode Unit 1 Adds Unit 2 Adds...
  • Page 9 - High temperature resistant engineering plastic case + aluminum base Movement - Pan/ Tile: 540°/260° 16bit Dimmer/Strobe - Dimming level: 0-100% perfect linear dimming system - Strobe: 1-25 times/second IP Rated - IP20, indoor only Weigh & Size - N.W：6KG - Size: 273*170*340mm Please Note: Specifications and improvements in the design of this unit and this manual are...

  • Page 10: How To Set The Unit

    subject to change without any prior written notice. 7.HOW TO SET THE UNIT To select any of the given functions, press the MENU button up to where the required function is showing on the display. Select the function by pressing the ENTER button and the display will blink.
  • Page 11 White 0-255 WhiteFine 0-255 0-255 Macro 0-255 Strobe 0-255 0-255 DimFine 0-255 0-255 PanFine 0-255 Tilt 0-255 TiltFine 0-255 Function 0-255 Reset 0-255 Zoom 0-255 ShapeSel 0-255 ShapeSpeed 0-255 ShapeFade 0-255 ShapeRed 0-255 ShapeGreen 0-255 ShapeBlue 0-255 ShapeWhite 0-255 BackDim 0-255 ShapeTransi 0-255...

  • Page 12: Channel Description

    Dimmer V1.01E Factory Password 0-255 0-255 Tilt 0-255 Zoom 0-255 Rotate 0-255 0-255 Green 0-255 Blue 0-255 White 0-255 Reset All Reset Off/Run Factory Reset Off/Run 8.CHANNEL DESCRIPTION 23 Channels Mode Function Value Description 0-255 0-540 degree X fine 0-255 16 bit 0-255 0-205 degree...
  • Page 13 4-200 Synchronous strobe from slow-fast strobe 201-215 Random strobe in low speed 216-234 Random strobe in middle speed 235-255 Random strobe in high speed R dimmer 0-255 From dark-bright G dimmer 0-255 From dark-bright B dimmer 0-255 From dark-bright W dimmer 0-255 From dark-bright 0-255...
  • Page 14 blue 0-255 Blue dimmer Blue fine 0-255 Blue dimmer fine white 0-255 White dimmer White fine 0-255 White dimmer fine 0-255 Linear CT control Color Macro 0-255 Color Macro function Synchronous strobe slow-fast （1HZ-25HZ） 4-103 104-107 Divide strobe from slow-fast 108-207 （1HZ-25HZ）...
  • Page 15 pattern 0-255 Pattern rotate Pattern speed 0-255 Pattern speed Pattern effect fade 0-255 Pattern effect R 0-255 Pattern effect G 0-255 Pattern effect B 0-255 Pattern effect W 0-255 Pattern dimmer 0-255 Pattern 0-100% dimmer Background 0-255 Background 0-100% dimmer dimmer Pattern transition 0-255...
  • Page 16 4-200 Synchronous strobe slow-fast strobe 201-215 Random strobe in low speed 216-234 Random strobe in middle speed 235-255 Random strobe in high speed R dimmer 0-255 G dimmer 0-255 B dimmer 0-255 W dimmer 0-255 0-255 Linear CT control Wash 0-255 Static effect 0-255...

  • Page 17: Trouble Shooting

    G7 LED dimmer 0-255 G7 LED dimmer B7 LED dimmer 0-255 B7 LED dimmer W7 LED dimmer 0-255 W7 LED dimmer 9.TROUBLE SHOOTING Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A.

  • Page 18: Cleaning And Maintenance

    1. The lamp is not working well. Check the mains voltage either too high or too low. 2. Internal temperature may be too high. Check if replacement of fan is needed on the head. E. No response to the sound 1.
  • Page 19 Clean the external lens surface at least every 20 days with a soft cloth  to avoid dirt/debris accumulation. Never use alcohol, solvents, or ammonia based cleaners.  MAINTENANCE Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized service technician.
  • Page 20 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
