RIUKOE Mac Aura 1915 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
Mac Aura 1915

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mac Aura 1915 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RIUKOE Mac Aura 1915

Summary of Contents for RIUKOE Mac Aura 1915

  • Page 1 Mac Aura 1915 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.SAFETY INSTRUCTION................2 4.INSTALLATION ..................4 5.TECHNICAL SPECIFICATION..............7 6.PANEL OPTATION ................... 9 7.CHANNEL DESCRIPTION (17/20CHS) ..........10 8.TROUBELSHOOTING ................19 9.CLEANING AND MAINTENANCE ............20...

  • Page 3: Statement

    1.STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction & problem owing to ignore the manual.

  • Page 4: Preventing Electric Shock

    installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock WARNING! Risk of electric shock. Always power off/unplug the fixture before removing any covers.  Ensure that the power is turned off when connecting the fixture to the AC ...

  • Page 5: Installation

    WARNING! Take measure to prevent personal injury. Do not look directly at the light source from close range.  Take precautions to prevent injury due to falls when working at height.  For permanent installation, ensure that the fixture is securely fastened to ...

  • Page 6: Dmx-512 Control Connection

    clamp to the included Omega Bracket using a M10 screw fitted through the center hole of the ‘omega bracket’. As an added safety measure be sure to attached at least one properly rated Safety Cable to the fixture using one of the safety cable rigging point integrated in the base assembly.

  • Page 7: Dmx-512 Connection With Dmx Terminator

    DMX-512 connection with DMX terminator: For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain.

  • Page 8: Dmx Address Setting

    DMX Address Setting: By using a universal DMX controller to control the units, you will need to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button up to when the DMX Address is showing on the display. Pressing the ENTER button and the display will blink.
  • Page 9 - Control mode: DMX512, master-slave operation, sound control - Channel mode: 14CH/ 25CH - Support RDM function, DMX software upgrade function - Optional network function support: artnet, klingnet, sacn, network protocol Display/Case/Base - Display mode: LCD display, lamp temperature display, Chinese and English display, reverse display - High temperature resistant engineering plastic case + aluminum base Focus...

  • Page 10: Panel Optation

    6.PANEL OPTATION Turn on the unit, press the MENU button into menu mode, and press the UP/DOWN button until the required function is shown on the monitor. Select the function by the ENTER button. Use the UP/DOWN button to choose the submenu, press the ENTER button to store and automatically return to the last menu.

  • Page 11: Channel Description (17/20Chs)

    DIMA_B 000-255 Sound Sense Sound Sense: [000%-100%] System information: The version: V51AP System Set Default Settings : [Yes?] Code Settings: Enter your 4 codes! Reset Reset System: [Yes?] 7.CHANNEL DESCRIPTION STD. EXT. Values Description 0 - 19 Shutter closed 20 - 24 Shutter open 25 - 64 Strobe 1 (fast →...
  • Page 12 205 - 209 Shutter open 210 - 224 Strobe 9: sine wave (fast → slow) 225 - 229 Shutter open 230 - 244 Strobe 10: burst 245 - 255 dimmer 0-255 0 → 100% intensity Zoom 0-255 Wide → narrow 0-255 0°...
  • Page 13 250 - 255 Illuminate display 0 - 9 Open. RGBW color mixing enabled 10 - 14 LEE 790 - Moroccan pink 15 - 19 LEE 157 - Pink 20 - 24 LEE 332 - Special rose pink 25 - 29 LEE 328 - Follies pink 30 - 34 LEE 345 - Fuchsia pink...
  • Page 14 150 - 154 LEE 105 - Orange 155 - 159 LEE 021 - Gold Amber 160 - 164 LEE 778 - Millennium Gold 165 - 169 LEE 135 - Deep Golden Amber 170 - 174 LEE 164 - Flame Red 175 - 179 Open Color wheel rotation effect...
  • Page 15 of FX • FX1 and FX2 run through cycles independently • Cycle duration is regular • Channel 16 and channel 18 adjust FX1 and FX2 independently Sync • FX1 and FX2 run through cycles in sync • Cycle duration is regular •...
  • Page 16 25 - 64 Strobe 1 (fast → slow) strobe 65 - 69 Shutter open effect 70 - 84 Strobe 2: opening pulse (fast → slow) 85 - 89 Shutter open 90 - 104 Strobe 3: closing pulse (fast → slow) 105 - 109 Shutter open 110 - 124...
  • Page 17 45 - 49 LEE 071 - Tokyo Blue 50 - 54 LEE 120 - Deep Blue 55 - 59 LEE 079 - Just Blue 60 - 64 LEE 132 - Medium Blue 65 - 69 LEE 200 - Double CT Blue 70 - 74 LEE 161 - Slate Blue 75 - 79...
  • Page 18 208 - 229 Counter-clockwise, slow → fast 230 - 234 Open Random color 235 - 239 Fast 240 - 244 Medium 245 - 249 Slow 250 - 255 Open Aura red 0-255 Red 0 → 100% Aura 0-255 Green 0 → 100% green Aura 0-255...
  • Page 19 FX: pre-programmed effects...

  • Page 20: Troubelshooting

    8.TROUBELSHOOTING Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connect power and main fuse. 2.

  • Page 21: Cleaning And Maintenance

    E. No response to the sound 1. Make sure the unit does not receive DMX signal.. 2. Check microphone to see if it is good by tapping the microphone. F. If The tilt belt is broken 1. The stepper motor might be damaged or the cable connected to the PCB is broken.
  • Page 22 MAINTENANCE Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized service technician. Should you need any spare parts, please order genuine parts from your local dealer.
  • Page 23 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...

This manual is also suitable for:

Aura z1915
