iWash 1240 Moving Head（Pixel Version）
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
(ML-WZ012)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iWash 1240 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RIUKOE iWash 1240

Summary of Contents for RIUKOE iWash 1240

  • Page 1 1240 Moving Head（Pixel Version） (ML-WZ012) This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual...

  • Page 2: Table Of Contents

    INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.SAFETY INSTRUCTION................2 4.INSTALLATION ..................4 5.DMX CONNECTION ................. 5 6.TECHNICAL SPECIFICATION..............8 7.HOW TO SET THE UNIT ................9 8.CHANNEL DESCRIPTION ..............12 9.TROUBLE SHOOTING ................17 10.CLEANING AND MAINTENANCE ............18...

  • Page 3: Statement

    1.STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction & problem owing to ignore the manual.

  • Page 4: Preventing Electric Shock

    installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock WARNING! Risk of electric shock. Always power off/unplug the fixture before removing any covers.  Ensure that the power is turned off when connecting the fixture to the AC ...

  • Page 5: Installation

    WARNING! Take measure to prevent personal injury. Do not look directly at the light source from close range.  Take precautions to prevent injury due to falls when working at height.  For permanent installation, ensure that the fixture is securely fastened to ...

  • Page 6: Dmx Connection

    clamp to the included Omega Bracket using a M10 screw fitted through the center hole of the ‘omega bracket’. As an added safety measure be sure to attached at least one properly rated Safety Cable to the fixture using one of the safety cable rigging point integrated in the base assembly.

  • Page 7: Dmx-512 Connection With Dmx Terminator

    DMX-512 connection with DMX terminator: For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain.

  • Page 8: Dmx Address Setting

    DMX Address Setting: By using a universal DMX controller to control the units, you will need to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button up to when the DMX Address is showing on the display. Pressing the ENTER button and the display will blink.

  • Page 9: Technical Specification

    6.TECHNICAL SPECIFICATION Power Supply - Voltage:AC100-240V,50/60Hz - Power:600W Light Source - Lamp source: Lamp : 12 X 40W RGBW 4in1 LED - Light source life: 50000h - Beam angle: 8°- 63° Protocols - Control mode: DMX512, master-slave operation, sound control, Auto - Channel mode: 58/17/11/18 CHs mode Display/Case/Base - Display mode: LCD display, lamp temperature display, Chinese and English...

  • Page 10: How To Set The Unit

    Weigh & Size - Net weight: 14kg - Carton Packing : 46*36**49cm, 17kgs Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. 7.HOW TO SET THE UNIT To select any of the given functions, press the MENU button up to where the required function is showing on the display.
  • Page 11 The main functions are as below: Dmx Address 001 - 512 EXT-58CH STD-17CH DMX Mode HST-11CH Fixture GUI-18CH Run Mode DMX/ SOUN/Host Pan Invert Close/Open Tilt Invert Close/Open 0 - 255 Pan Fine 0 - 255 Tilt 0 - 255 Tilt Fine 0 - 255 P/T Speed...
  • Page 12 Color 0 - 255 DackDim 0 - 255 Zoom 0 - 255 Reset 0 - 255 Current Time xxxh Time Total Time xxxh Power Count TRUE Tilt TRUE Sensor Zoom TRUE Information Temp TRUE TRUE Head Temp xxx C Temperature Fan Speed xxxx RPM Panel...

  • Page 13: Channel Description

    White Motor Reset Run/OFF Fixture Reset Factory Run/OFF Language EN/CH Display Display Flip Normal/Reverse Display Mode Show/60s 8.CHANNEL DESCRIPTION STD- EXT- GUI- HST- VALUE FUNCTION 17CH 58CH 18CH 11CH 000-255 Pan 0 ° - 540° 000-255 Pan Fine 000-255 Tilt 0 ° - 240° 000-255 Tilt Fine 000-255...
  • Page 14 effect 252-255 Open 000-255 Red 0% ~ 100% 000-255 Green 0% ~ 100% 000-255 Blue 0% ~ 100% 000-255 White 0% ~ 100% 000-255 000-255 Saturation 000-255 Intensity 000-255 Red1 000-255 Green1 000-255 Blue1 000-255 White1 000-255 Red2 000-255 Green2 000-255 Blue2 000-255...
  • Page 15 000-255 Red6 000-255 Green6 000-255 Blue6 000-255 White6 000-255 Red7 000-255 Green7 000-255 Blue7 000-255 White7 000-255 Red8 000-255 Green8 000-255 Blue8 000-255 White8 000-255 Red9 000-255 Green9 000-255 Blue9 000-255 White9 000-255 Red10 000-255 Green10 000-255 Blue10 000-255 White10 000-255 Red11 000-255...
  • Page 16 000-255 Color Macro NULL 001-006 LED1 007-013 LED2 014-020 LED3 021-027 LED4 028-034 LED5 034-041 LED6 042-048 LED7 049-055 LED8 056-062 LED9 063-069 LED10 070-076 LED11 077-083 LED12 084-090 3 leds clock static graphic 1 091-097 3 leds clock static graphic 2 098-104 3 leds clock static graphic 3 105-111...
  • Page 17 168-174 1led Flowing water dynamic effect 175-181 2leds Flowing water dynamic effect 182-188 3leds Flowing water dynamic effect 189-195 3 light-emitting diode inverted Dynamic effect of slow running clock 196-202 4 leds clock slow running dynamic effect 203-209 3 leds clock slow running dynamic effect 210-216 wave running dynamic effect...

  • Page 18: Trouble Shooting

    100-200 Auto 201-255 NULL 9.TROUBLE SHOOTING Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connect power and main fuse. 2.

  • Page 19: Cleaning And Maintenance

    2. Internal temperature may be too high. Check if replacement of fan is needed on the head. E. No response to the sound 1. Make sure the unit does not receive DMX signal.. 2. Check microphone to see if it is good by tapping the microphone. F.
  • Page 20 There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized service technician. Should you need any spare parts, please order genuine parts from your local dealer. Factory: No.31 Zhongxing Road Baiyun District Guangzhou,China +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
