- Page 1 7x40W ZOOM LED MOVING HEAD ML-WZ007 User Manual KEEP THIS MANUAL FOR FUTURE NEED...
- Page 2 INDEX STATEMENT ACCESSORIES SAFETY INSTRUCTION GENERAL GUIDELINES INSTALLATION TECHNICAL SPECIFICATIN CONTROL SYSTEM HOW TO SET THE UNIT HOW TO CONTROL THE UNIT CLEANING AND MAINTENANCE STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction &...
-
Page 3: Safety Instruction
ACCESSORIES These items are packed together with the product: Name Quantity Unit Remark DMX CABLE POWER CABLE SAFETY INSTRUCTION Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. -
Page 4: General Guidelines
GENERAL GUIDELINES NEVER OPEN THIS FIXTURE WHILE IN USE! During the initial operation of this fixture, a light smoke or smell may emit from the interior of the fixture. This is a normal process and is caused by excess paint in the interior of the casing burning off from the heat associated with the lamp and will decrease gradually over time. -
Page 5: Installation
INSTALLATION C A U T I O N S For added protection, mount the fixture in areas outside walking paths, seating areas, or in areas were unauthorized personnel might reach the fixture. Ambient operating temperature range for this fixture is 5°... - Page 6 where is out of the touch of people DMX-512 control connection: Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other side to the male 3-pin XLR input of the moving head. You can chain multiple Moving head together through serial linking.
-
Page 7: Control System
Power Consumption：350W LED：7X 40W OSRAM RGBW LED Strobe: 1-25 times/second PAN: 540°/240° 16bit Beam angle: 4.5°-45° Dimmer: 0-100% linear dimming system N.W：10 Kg Small，Fast, Functional LED moving head wash zoom. Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice CONTROL SYSTEM The DMX512 is widely used in intelligent lighting control, with a DMX 512... -
Page 8: How To Set The Unit
HOW TO SET THE UNIT MAIN FUNCTION To select any of the given functions, press the MENU button up to where the required function is showing on the display. Select the function by pressing the ENTER button and the display will blink. Use the DOWN and UP buttons to change the mode. - Page 9 Pan Fine 0 - 255 Tilt 0 - 255 Tilt Fine 0 - 255 0 - 255 0 - 255 0 - 255 Cur Time xxxh TimeInfo Show Time xxxh PowerCnt OK/NG Tilt OK/NG SenSor Zoom OK/NG Fix Info Temp OK/NG OK/NG Temprat...
-
Page 10: How To Control The Unit
Reset Cance/Run FixReset Factory Cance/Run Language EN/CH Display DispFlip Open/Close DispMode Show/60s HOW TO CONTROL THE UNIT 1：address code setting ⚫ Set dmx address in DMX menu ⚫ Set the same address or different according to needs A001 is default setting， press ENTER into address set， UP/DOWN to change code，then ENTER，... - Page 11 strobe. 4.Fix info Time display，sensor，temp and cur soft version 5.home setting set the pan, tilt, zoom and R,,G,B,W 6：reset [RESET]motor reset mode，select【ON】reset，【OFF】not reset press【ENTER】into【Reset default】，select【default】，press 【ENTER】 press【down】【up】to choose，【ON】reset deault，【OFF】stay cur setting，press【ENTER】confirm 7：display setting： language：Chinese/ English display flip display mode setting CHANNEL DESCRIPTION (17 CHANNEL): FUNCTION VALUE...
- Page 12 252 - 255 OPEN 239 - 251 RANDOM FAST STROBE 226 - 238 RANDOM MEDIUM STROBE 213 - 225 RANDOM SLOW STROBE Strobe 208 - 212 OPEN 108-207 SLOW PULSATION - FAST PULSATION 104 - 107 OPEN 4-103 SLOW STROBE - FAST STROBE 0 - 3 CLOSED 225-255...
- Page 13 149-150 Primary Green 147-148 Special lavender Pale Lavender Deep Golden Amber 142-144 Medium Blue 138-141 Bright Pink 136-137 Mauve 134-135 Dark Green 131-133 Leaf Green 129-130 Dark Blue Light Blue Steel Blue Med Blu Green Peacock Blue 123-124 Magenta 121-122 Dark Pink Middle Rose Light Salmon...
- Page 14 Light Pink 35-44 Sunrise Red 32-34 Dark Amber Gold Amber Medium Amber Fire 27-28 Surprise Peach 23-26 Straw Tint 20-22 Medium Yellow Black White 5000 K White 3700 K White 7000 K Magenta Yellow Cyan Blue Green Macro color OFF Zoom 0-255 NARROW BEAM - WIDE BEAM...
-
Page 15: Cleaning And Maintenance
Pan Fine 0-255 Pan Fine Tilt 0-255 Tilt Tilt Fine 0-255 Tilt Fine P/T Speed 0-255 P/T Speed 0-255 0-255 Saturation Saturation Intensiyt 0-255 Intensiyt 0-255 SLOW STROBE - FAST STROBE Strobe 0-255 NARROW BEAM - WIDE BEAM Zoom Control 0-255 Control 0-127... - Page 16 MAINTENANCE Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized service technician. Should you need any spare parts, please order genuine parts from your local dealer. Please refer to the following points during routine inspections: •...
