150W LED Spot Moving Light
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
(ML-MS150)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ML-MS150 and is the answer not in the manual?

Questions and answers

Related Manuals for RIUKOE ML-MS150

Summary of Contents for RIUKOE ML-MS150

  • Page 1 150W LED Spot Moving Light (ML-MS150) This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual...

  • Page 2: Table Of Contents

    INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.SAFETY INSTRUCTION................2 4.INSTALLATION ..................4 5.TECHNICAL SPECIFICATION..............7 6.PANEL OPTATION ................. 10 7.CHANNEL DESCRIPTION ..............11 8.TROUBELSHOOTING ................14 9.CLEANING AND MAINTENANCE ............16...

  • Page 3: Statement

    1.STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction & problem owing to ignore the manual.

  • Page 4: Preventing Electric Shock

    installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock WARNING! Risk of electric shock. Always power off/unplug the fixture before removing any covers. ⚫ Ensure that the power is turned off when connecting the fixture to the AC ⚫...

  • Page 5: Installation

    WARNING! Take measure to prevent personal injury. Do not look directly at the light source from close range. ⚫ Take precautions to prevent injury due to falls when working at height. ⚫ For permanent installation, ensure that the fixture is securely fastened to ⚫...

  • Page 6: Dmx-512 Control Connection

    clamp to the included Omega Bracket using a M10 screw fitted through the center hole of the ‘omega bracket’. As an added safety measure be sure to attached at least one properly rated Safety Cable to the fixture using one of the safety cable rigging point integrated in the base assembly.

  • Page 7: Dmx-512 Connection With Dmx Terminator

    DMX-512 connection with DMX terminator: For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain.

  • Page 8: Dmx Address Setting

    DMX Address Setting: By using a universal DMX controller to control the units, you will need to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button up to when the DMX Address is showing on the display. Pressing the ENTER button and the display will blink.
  • Page 9 - Light source life: 50000h - Color temperature: 9000k - LED life: 50000 hours - Beam angle: 15 ° Protocols - Control mode: DMX512/Master-Slave/Auto run - Channel mode: 16/14/12/10 DMX Channel Display/Case/Base - Display mode: LCD display, lamp temperature display, Chinese and English display, reverse display - High temperature resistant engineering plastic case + aluminum base Color Wheel...
  • Page 10 Automatic XY error correction, rich built-in program Dimmer/Strobe - Dimming level: 0-100% perfect linear dimming system - Strobe: 0-25 Hz Synchronous pulse strobe, random pulse strobe IP Rated - IP20, indoor only Weigh & Size - Dimensions: 270(D)*270(W)*470(H)mm - Packing size: 305(D)*305(W)*500(H)mm - Net Weight: 10.6kg - Gross Weight:12.6kg Feature:...

  • Page 11: Panel Optation

    Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. 6.PANEL OPTATION Turn on the unit, press the MENU button into menu mode, and press the UP/DOWN button until the required function is shown on the monitor.

  • Page 12: Channel Description

    Factory Set Ver V1 System DMX Address Info Temperature 7.CHANNEL DESCRIPTION CH10 CH12 14CH 16CH Function CH Value Description 0-255 0-540° Pan fine 0-255 Pan Fine Tilt 0-255 0-270° Tilt Fine 0-255 Tilt Fine X, Y speed 0-255 From fast to slow LED Dimmer 0-255 From dark to bright...
  • Page 13 64-79 Color 4 80-95 Color 5 96-111 Color 6 112-127 Color 7 128-191 CW from slow to fast 192-255 CCW from slow to fast Open 7-13 Gobo 1 14-20 Gobo 2 21-27 Gobo 3 28-34 Gobo 4 35-41 Gobo 5 42-48 Gobo 6 49-55...
  • Page 14 113-119 Gobo 1 shake speed from slow to fast 120-127 Open 128-191 Gobo Rotate CW slow to fast 192-255 Gobo Rotate CCW slow to fast CH10 6 rotation 0-15 open gobos +White 16-31 Gobo1 32-47 Gobo2 48-63 Gobo3 64-79 Gobo4 80-95 Gobo5 96-127...

  • Page 15: Troubelshooting

    0-63 Open CH11 CH11 CH13 Prism 64-255 Prism In 0-15 Stop CH10 CH12 CH12 CH14 Prism Rotation 16-135 Rotate CW slow > fast 136-255 Rotate CCW slow > fast No action self-setting CH13 CH15 8-131 Auto mode Program 132-255 Sound mode 0-249 No function CH14...
  • Page 16 2. If the DMX LED is on and no response to the channel, check the address settings and DMX polarity. 3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the unit or the previous one. 4.

  • Page 17: Cleaning And Maintenance

    9.CLEANING AND MAINTENANCE Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: CLEANING Frequent cleaning is recommended to insure proper function, optimized light output, and an extended life. The frequency of cleaning depends on the environment in which the fixture operates: damp, smoky or particularly dirty environments can cause greater accumulation of dirt on the fixture’s optics.
