500W BSW Moving Head Light
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
(ML-BSW500)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ML-BSW500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RIUKOE ML-BSW500

Summary of Contents for RIUKOE ML-BSW500

  • Page 1 500W BSW Moving Head Light (ML-BSW500) This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual...

  • Page 2: Table Of Contents

    INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.SAFETY INSTRUCTION................2 4.INSTALLATION ..................4 5.TECHNICAL SPECIFICATION..............7 6.PANEL OPTATION ................. 10 7.CHANNEL DESCRIPTION (23CHS) ............18 8.TROUBELSHOOTING ................23 9.CLEANING AND MAINTENANCE ............24...

  • Page 3: Statement

    1.STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction & problem owing to ignore the manual.

  • Page 4: Preventing Electric Shock

    Review the following safety precautions carefully before installing or operating the fixture. This fixture must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock WARNING! Risk of electric shock.

  • Page 5: Avoid Personal Injury

    Avoid personal injury WARNING! Take measure to prevent personal injury. Do not look directly at the light source from close range. ⚫ Take precautions to prevent injury due to falls when working at height. ⚫ For permanent installation, ensure that the fixture is securely fastened to ⚫...

  • Page 6: Dmx-512 Control Connection

    Omega Bracket using a M10 screw fitted through the center hole of the ‘omega bracket’. As an added safety measure be sure to attached at least one properly rated Safety Cable to the fixture using one of the safety cable rigging point integrated in the base assembly.

  • Page 7: Dmx Address Setting

    electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain.

  • Page 8: Technical Specification

    multi-point, half-duplex protocol. Only allowed at the same time One port is the output of the host, so, pay attention to the following points when using RDM： To use a console or host device that supports the RDM protocol host； ⚫...
  • Page 9 - Control mode: DMX512/Master-Slave/Auto run/ RDM - Channel mode: 23 CHs - Macro function: console reset function, self-propelled mode, master-slave mode Display - Display mode: LCD display, key + touch dual operation mode Cooling system - Adopt axial fan to enhance cooling With electronic temperature control overheating protection, electronic temperature control automatic power-off protection when the overheating system fails...
  • Page 10 - Pan: 540 (16bit) degree + fine, electronic error correction - Tilt: 270 (16bit) degree + fine, electronic error correction Dimmer/Strobe - Dimming level: 0-100% perfect linear dimming system - High-speed Strobe: 0-30 Hz Synchronous pulse strobe, Strobe macro function IP Rated - IP20, indoor only - Working temperature：-20 °- 40 °...

  • Page 11: Panel Optation

    Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. 6.PANEL OPTATION 6.1 Brief The light panel diagram show as Figure 3, Left area is TFT Displayer, support touch, and right area is KEY, both of touch and KEY can operate light and setting.
  • Page 12 touch function,, the KEY can been choose to set the parameter 6.2.2 Parameter value setting When the selected item is value need to been modified, the dialog shown in Figure 4 will popup. Figure 2 Dialog of value setting Modify value：Can quickly modify value via pull the slider to the desired ⚫...
  • Page 13 Figure 3 Dialog of confirm 6.2.4 Sub Menu (Parameter) Chick item of main menu, enter corresponding sub menu, shown in Figure 6, total 6 sub menu, includes class of parameter and status: • ADDRESS：Set light DMX address. • WORKMOD：Set light work mode, master or slave mode when in auto run mode.
  • Page 14 6.3 Operation and parameter instruction Via following operation, enter sub menu(parameter menu) shown in Figure 6 • In main menu, chick 1/6 function button into corresponding parameter menu. • In sub menu(page), chick main item on the left side of displayer, can shift to corresponding sub menu(page) quickly.
  • Page 15 Figure 6 page of work mode • DMX Ctrl: Choose to set DMX Mode, • Auto Run: Choose to set Auto Mode, • Sound Ctrl: Choose to set Sound Mode, • M/S Choose: Available just in ‘AUTO RUN’ or ‘SOUND Ctrl’ mode. ON-->...
  • Page 16 Figure7 page of display • Language: English / 中文. • Screen Saver: when panel is idle(these is no operation in 10 second), displayer will enter saver status OFF--> No screen saver. Mode1--> Power-saving mode, turn off the display. Mode2--> Displays the current address. Mode3-->...
  • Page 17 Figure 8 page of Test • PAN: range for 0 to 255; • TILT: range for 0 to 255; • FOCUS: range for 0 to 255; • COLOR: range for 0 to 255; • GOBO: range for 0 to 255; •...
  • Page 18 Figure 9 page of run parameter • Pan Invert: Reverse PAN move OFF--> Pan Normal move.(Default) ON--> Reverse PAN move. • Tilt Invert: Reverse TILT move OFF--> Tilt Normal move.(Default) ON--> Reverse Tilt move. • P/T Rectify: Disable or enable position rectify function OFF-->...

  • Page 19: Channel Description (23Chs)

    Figure 10 page of status • Work Mode: Show the current working mode. • Address: Show the current address. • Version: Show the version of the lamp. • Elapse: Working hours after turn on. • Total: Cumulative hours of operation 7.CHANNEL DESCRIPTION (23CHs) 23CH FUNCTION...
  • Page 20 4-103 Pulse strobe slow to fast 104-107 White 108-207 Random strobe slow to fast 208-212 White 213-251 Rand strobe slow to fast 252-255 White 0-127 Linear colour 128-131 Colour1 132-135 Colour2 136-139 Colour3 140-143 Colour4 144-147 Colour5 148-151 Colour6 152-155 Colour7 156-159 Colour8...
  • Page 21 226-255 Rotate reverse (slow to fast) 110-119 Color 2+Color 3 120-129 Color 3+Color 4 130-139 Color 4+Color 5 140-149 Color 5+Color 6 150-159 Color 6+Color 7 160-169 Color 7+Color 8 170-179 Color 8+Color 9 180-215 Fast to slow positive rainbow 216-220 Stop 221-255...
  • Page 22 50-54 Gobo 10 55-59 Shake slow to fast Gobo1 60-64 Shake slow to fast Gobo2 65-69 Shake slow to fast Gobo3 70-74 Shake slow to fast Gobo4 75-79 Shake slow to fast Gobo5 80-84 Shake slow to fast Gobo6 85-89 Shake slow to fast Gobo7 90-94 Shake slow to fast Gobo8...
  • Page 23 70-79 Gobo 7 80-89 Shake slow to fast GOBO1 90-99 Shake slow to fast GOBO2 100-109 Shake slow to fast GOBO3 110-119 Shake slow to fast GOBO4 120-129 Shake slow to fast GOBO5 130-139 Shake slow to fast GOBO6 140-149 Shake slow to fast GOBO7 150-200 Rotate forward (fast to slow)

  • Page 24: Troubelshooting

    188-195 Stop 196-255 Rotate reverse (slow to fast) 0-127 No function CH22 FROST 128-255 Frost 0-209 None 210-215 Reset XY motor over 4 second 216-219 None CH23 RESET 220-235 Reset Effect motor over 4 second 236-239 None 240-255 Reset all after 4 second 8.TROUBELSHOOTING Following are a few common problems that may occur during operation.

  • Page 25: Cleaning And Maintenance

    connectors or on PCB of the unit or the previous one. 4. Try to use another DMX controller. 5. Check to see if the DMX cables run near or run alongside to high voltage cables that may cause damage or interference to DMX interface circuit. C.
  • Page 26 some suggestions for easy troubleshooting: CLEANING Frequent cleaning is recommended to insure proper function, optimized light output, and an extended life. The frequency of cleaning depends on the environment in which the fixture operates: damp, smoky or particularly dirty environments can cause greater accumulation of dirt on the fixture’s optics. Clean the external lens surface at least every 20 days with a soft cloth •...
  • Page 27 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
