- Page 1 Pixel Bar 1240 Moving Head (ML-BZ1240) This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual...
-
Page 2: Table Of Contents
INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.SAFETY INSTRUCTION................2 4.INSTALLATION ..................4 5.TECHNICAL SPECIFICATION..............7 6.HOW TO SET THE UNIT ................8 7.CHANNEL DESCRIPTION (20/57CHS) ..........10 8.TROUBELSHOOTING ................14 9.CLEANING AND MAINTENANCE ............15... -
Page 3: Statement
1.STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction &... -
Page 4: Preventing Electric Shock
Review the following safety precautions carefully before installing or operating the fixture. This fixture must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock WARNING! Risk of electric shock. -
Page 5: Avoid Personal Injury
⚫ CAUTION: Exterior surface temperature after 5 min. operation = 45 °C (113 °F). Steady state = 60 °C (140 °F). Avoid personal injury WARNING! Take measure to prevent personal injury. ⚫ Do not look directly at the light source from close range. ⚫... -
Page 6: Clamp Mounting
The equipment must be fixed by professionals. And it must be fixed at a place where is out of the touch of people Clamp mounting The moving head provides a unique mounting bracket assembly that integrates the bottom of the base, the included ‘Omega Bracket’ and the Safety Cable rigging point in one unit .When mounting this fixture to truss be sure to sere to secure an appropriately rated clamp to the included Omega Bracket using a M10 screw fitted... -
Page 7: Dmx Address Setting
For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain. -
Page 8: Technical Specification
5.TECHNICAL SPECIFICATION Power Supply - Voltage: AC90-240V,50/60Hz - Maximum Power:500W Light Source - Lamp source: 12pcs 40w high brightness four in one lamp beads - Light source life: an average of 20,000 hours Protocols - Control signal: DMX512, master-slave, voice control - Control channel: 20/57 CHs Modes Display/Case/Base - Display mode: TFT color display with 180°... -
Page 9: How To Set The Unit
IP Rated - IP20, indoor only Size & Weight - Product size: 102*10.75 *26.6cm - Weight: 15 Kgs Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. 6.HOW TO SET THE UNIT 6.1 Fixture Overview 1. -
Page 10: Main Function
6.3 Main Function To select any of the given functions, press the MENU button until the required function is showing on the display. Select the function by pressing the ENTER button and the display will blink. Use the DOWN/UP buttons to change the mode. Once the required mode has been selected, press the ENTER button to setup, to go back to the functions without any change press the MENU button again. -
Page 11: Channel Description (20/57Chs)
Panel Vx.xxx Software Version Dimmer Vx.xxx Password 0 - 255 Tilt 0 - 255 Zoom1 0 - 255 Zoom2 0 - 255 Factory 0 - 255 Green 0 - 255 Blue 0 - 255 White 0 - 255 Reset Run/OFF Fixture Reset Factory Run/OFF... - Page 12 Zoom 2 0 - 255 Zoom 1 Dimmer 0 - 255 Dimmer 8bit DimFine 0 - 255 Dimmer 16bit 0 - 3 Close 4 - 103 Regular Strobe, From slow to fast 104 - 107 Open 108 - 207 Random strobe, From slow to fast Strobe 208 - 212 Open...
- Page 13 … … … … 188 - 190 Dynamic Effect 40 191 - 193 Dynamic color Effect 1 … … … … 218 - 220 Dynamic color Effect 10 221 - 255 Dynamic color Effect 11 Dynamic Effect Speed From slow Effect Speed 0 - 255 to fast...
- Page 14 DimFine 0 - 255 Dimmer 16bit 0 - 3 Close 4 - 103 Regular Strobe, From slow to fast 104 - 107 Open 108 - 207 Random strobe, From slow to fast Strobe 208 - 212 Open 213 - 225 Random Slow Strobe 226 - 238 Random Faster Strobe...
-
Page 15: Troubelshooting
Fixture Reset 101-120 Reset Reserve No Function 8.TROUBELSHOOTING Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. -
Page 16: Cleaning And Maintenance
D. The lamp is cutting out intermittently 1. The lamp is not working well. Check the mains voltage either too high or too low. 2. Internal temperature may be too high. Check if replacement of fan is needed on the head. E. - Page 17 damp, smoky or particularly dirty environments can cause greater accumulation of dirt on the fixture’s optics. Clean the external lens surface at least every 20 days with a • soft cloth to avoid dirt/debris accumulation. Never use alcohol, solvents, or ammonia based cleaners. •...
