  • Page 1 Focus Beam 150 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.SAFETY INSTRUCTION................2 4.INSTALLATION ..................4 5.TECHNICAL SPECIFICATION..............7 6.PANEL OPERATION ................9 7.CHANNEL DESCRIPTION (17/20CHS) ..........19 8.TROUBELSHOOTING ................22 9.CLEANING AND MAINTENANCE ............24...

  • Page 3: Statement

    1.STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction & problem owing to ignore the manual.

  • Page 4: Preventing Electric Shock

    Review the following safety precautions carefully before installing or operating the fixture. This fixture must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock WARNING! Risk of electric shock.

  • Page 5: Avoid Personal Injury

    Avoid personal injury WARNING! Take measure to prevent personal injury. Do not look directly at the light source from close range. ⚫ Take precautions to prevent injury due to falls when working at height. ⚫ For permanent installation, ensure that the fixture is securely fastened to ⚫...

  • Page 6: Dmx-512 Control Connection

    mounting this fixture to truss be sure to sere to secure an appropriately rated clamp to the included Omega Bracket using a M10 screw fitted through the center hole of the ‘omega bracket’. As an added safety measure be sure to attached at least one properly rated Safety Cable to the fixture using one of the safety cable rigging point integrated in the base assembly.

  • Page 7: Dmx-512 Connection With Dmx Terminator

    DMX-512 connection with DMX terminator: For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain.

  • Page 8: Dmx Address Setting

    DMX Address Setting: By using a universal DMX controller to control the units, you will need to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button up to when the DMX Address is showing on the display. Pressing the ENTER button and the display will blink.
  • Page 9 - Support RDM function, DMX software upgrade function Display/Case/Base - Display mode: LCD display, lamp temperature display, Chinese and English display, reverse display - High temperature resistant engineering plastic case + aluminum base Color Wheel - Color plate: 14colors + open, with rainbow effect Gobo Wheel - Static Gobo Wheel: 10 fixed gobos + 3 glass gobos + white Prisms...

  • Page 10: Panel Operation

    - IP20, indoor only Weigh & Size - Net weight: 12kg - Product size: 300*210*510mm - G.W.:15kg - Package size: 54*38*41cm Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. 6.PANEL OPERATION 6.1 Brief The light panel diagram show in below, above area is fixture description, below area...

  • Page 11: Operation

    6.2 Operation 6.2.1 Operate fixture with touch or encoder/button The left area is TFT Displayer and touch(product which support touch), chick ⚫ item or value with finger will to complete operation of set light setting(parameters) or view light state. The area on the right hand side is rotary encoder with button or key, As ⚫...

  • Page 12: Boolean Parameter Setting

    Modify value: Can quickly modify value via pull the slider to the desired ⚫ position, or click the button of ‘up’ or ‘down’ whit finger on the right side to set the exact desired value, another way is roll encoder on the right hand side of panel.

  • Page 13: Sub Menu (Parameter)

    6.2.4 Sub Menu (Parameter) 6.3 Operation and parameter instruction Chick item of main menu, enter corresponding sub menu shown in Figure 6, In main menu, chick 1/6 function button into corresponding parameter menu. In sub menu(page), chick main item on the left side of displayer, can shift to corresponding sub menu(page) quickly.
  • Page 14 number of channels, automatically filter the unusable address (512 - the current number of channels). Fixture support RDM protocol, remote address can be set through RDM. ⚫ 6.3.2 Fixture operating mode setting Through the page shown in below, the operating mode of the fixture can be set and the lamp can be controlled.

  • Page 15: Set Display

    (Lamp light source) pop-up confirmation dialog box, select "SURE" to confirm the current operation, turn on or off the lamp, switch time interval limited to 30 Lamp seconds switch the current lamp output is off The current lamp output is turned on Scene mode applies to a single or a small number of fixture, just output a fixed scene, or need to run a simple program, you no need connect to the console, in the scene page can be edited.
  • Page 16 Set the indication mode of DMX signal indicator. Mode1 When signal is bright, no signal is off. Indicate Mode2 When signal is off, no signal is bright. Mode3 When signal is flash, no signal is off. Set the screen backlight for 10 seconds without operation Screen Light 1~10 6.3.4 Scene...

  • Page 17: Set Light Run Parameter

    preventing multiple consecutive resets. Looking at this page, you can get the current channel table slot of the fixture. For specific channel data, please refer to the detailed channel description 6.3.5 Set light run parameter Enter the page shown in below, adjust the field parameters of fixture, facilitate the installation of fixture, etc.

  • Page 18: Status And Information

    No signal, keep the last frame DMX data output. (lamp light source) Set the way to first open the lamp after power up Turn on the lamp at power up and reset the lamp after 30 Power on seconds. Lamp mode Reset the fixture after 3 seconds when power-on, and turn on After reset the lamp after reset.
  • Page 19 No display, indicating that the motor has no Hall, 0 indicating Hall that the motor leaves the correction position point, 1 indicating that the motor is in the correction position point Status Display motor reset status Stepper info Display real-time position value of PAN optocoupler feedback TILT Display real-time position value of TILT optocoupler feedback Displays the PAN TILT optocoupler two signal level state,...

  • Page 20: Channel Description (17/20Chs)

    Light Show the temperature of the current light source, "---" means Temperature no detection. Panel Displays the temperature of the current display panel or the Temperature ambient temperature. Sensor1 Display the ambient temperature of the motherboard Temperature temperature or the motherboard installation position. Display the information and version of the current fixture, important reference for after sales maintenance.
  • Page 21 12-16 Color3 17-20 Color4 21-24 Color5 25-28 Color6 29-33 Color7 34-37 Color8 38-41 Color9 42-45 Color10 46-50 Color11 51-54 Color12 55-58 Color13 59-63 Color14 64-191 Linear color 192-223 Fast to slow forward rotation 224-255 Slow to fast reverse rotation Turn off the strobe STOP / STROBE 4-250 From slow to fast pulse stroboscope...
  • Page 22 40-44 Gobo8 45-49 Gobo9 50-54 Gobo10 55-59 Gobo11 60-64 Gobo12 65-69 Gobo13 70-127 Fast to slow reverse rotation 128-131 Stop 132-190 Slow to fast forward rotation 191-195 Gobo 1 shake, Slow to fast 196-200 Gobo 2 shake, Slow to fast 201-205 Gobo 3 shake, Slow to fast 206-210...

  • Page 23: Troubelshooting

    193-255 Slow to fast reverse rotation 0-127 Prism2 excluded PRISM2 INSERTION 128-255 Prism2 inserted 0-127 excluded FROST/ RAINBOW 128-191 Frost inserted 192-255 Colorful inserted FOCUS 0-255 From far to near CH10 0-255 Angle 0-540 CH11 PAN FINE 0-255 Angle 0-2 CH12 TILT 0-255...
  • Page 24 A. The unit does not work, no light and the fan does not work 1. Check the connect power and main fuse. 2. Measure the mains voltage on the main connector. 3. Check the power on LED to see if it can be light up or not. B.

  • Page 25: Cleaning And Maintenance

    9.CLEANING AND MAINTENANCE Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: CLEANING Frequent cleaning is recommended to insure proper function, optimized light output, and an extended life. The frequency of cleaning depends on the environment in which the fixture operates: damp, smoky or particularly dirty environments can cause greater accumulation of dirt on the fixture’s optics.
  • Page 27 Factory: No.31 Zhongxing Road Baiyun District Guangzhou,China +86-20-2904 6476 info@ricostagelight.com YouTube www.riukoe.com Facebook...
