(SD & GZ Wireless Version)
This product manual contains important information about the safe
installation and use of this projector. Please read and follow these
instructions carefully and keep this manual in a safe place for future
reference.
User manual
Please read the instructions carefully before use
WiB18 IPRO
Advertisement
Table of Contents
Related Manuals for RIUKOE WiB18 IPRO
Summary of Contents for RIUKOE WiB18 IPRO
- Page 1 WiB18 IPRO (SD & GZ Wireless Version) This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Information....................2 2. IP65 Rated ......................3 3. Configuring the fixture for DMX control ............... 4 4. Cleaning ........................ 5 5. DMX Channel ....................... 5 6. Control menu ......................8 7. WiFi App Setting ....................11 8. -
Page 3: Safety Information
STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 4: Ip65 Rated
Install in a location that prevents accidental contact with the fixture. ⚫ Install only in a well-ventilated space. ⚫ Install only in accordance with applicable building codes. ⚫ Do not paint, cover or modify the fixture. ⚫ Keep all flammable materials away from the fixture. ⚫... -
Page 5: Configuring The Fixture For Dmx Control
define the degree of protection. The first digit (Foreign Bodies Protection) indicates the extent of protection against particles entering the fixture and the second digit (Water Protection) indicates the extent of protection against water entering the fixture. An IP65 rated lighting fixture is one, which has been designed and tested to protect against the ingress of dust (6) and high-pressure water jets from any direction (5). -
Page 6: Cleaning
4. Cleaning To maintain optimal performance, regular cleaning is essential. Cleaning schedules will vary depending on the operating environment, and the installation should therefore be checked at frequent intervals within the first few weeks of operation to see whether cleaning is necessary. This procedure will allow you to assess cleaning requirements in your particular situation. - Page 7 141-150 CT 6400K 151-160 CT 6800K 161-170 CT 7200K 171-180 CT 7600K 181-190 CT 8000K 191-200 CT 8400K 201-210 CT 8800K 211-220 CT 9200K 221-230 CT 9600K 231-240 CT 10000K 241-255 NO FUNCTION 0-255 1-255 Blue 0-100% 1-255 Red 0-100% 1-255 Green 0-100% 0-255 1-255 White 0-100%...
- Page 8 111-120 CT 5200K 121-130 CT 5600K 131-140 CT 6000K 141-150 CT 6400K 151-160 CT 6800K 161-170 CT 7200K 171-180 CT 7600K 181-190 CT 8000K 191-200 CT 8400K 201-210 CT 8800K 211-220 CT 9200K 221-230 CT 9600K 231-240 CT 10000K 241-255 NO FUNCTION 0-9Closed light 10-50Static color mixing 51-100 Jump mode...
-
Page 9: Control Menu
6. Control menu Display: OPERATING INSTRUCTION Press "Menu" to "Set DMX Address", and press "ENTER" keys to enter into Show "Set DMX Address DMX Address:001",Press the "UP and DOWN" keys to amended Press "ENTER" keys to save and Exit, Press the "MENU" Keys does not save and Exit Display Mode Function Description... - Page 10 12KHZ 12K Refresh Frequency 25KHZ 25K Refresh Frequency Red:0-255 Red Manual Dimming Green:0-255 Green Manual Dimming Blue:0-255 Blue Manual Dimming White:0-255 White Manual Dimming Custom Yellow:0-255 Yellow/Amber Manual Dimming UV:0-255 Purple Manual Dimming Static Colour:01-32 32 Types Static Color Mixing Speed:00-16 Strobe Speed (static color mixing when the speed is 00)
- Page 11 Clear Paring Long press “Enter” Key, select GZ/RD mode Run Time 2/4/6/8 hour Lamp usage time setting ON/OFF One click on/off Key Power (MENU key for this function) Always on Display Normally Open Display standby for X seconds and Back Light turn off the screen ON/OFF Infrared remote control on/off...
-
Page 12: Wifi App Setting
• The frequency band indicator light is red slow flashing when the host sends, and green slow flashing when the slave receives. • In the menu Wireless mode, the 7 frequency bands of wireless 2.4G can be adjusted, and the corresponding light colors of the 7 frequency bands are as follows (01 red/02 green/03 yellow/04 blue/05 light blue/06 purple/07 white) •... -
Page 13: Ir Remote Control
module is turned on，at this point can be set through the mobile to connect control. Open the phone settings function, find the wireless and network WLAN items, connect the name of LED_xxx equipment, as shown pics bellows ： When the connection is successful, exit the phone function settings, open the LED LAMP application software，select the “LED LIGHT”... -
Page 14: Wireless Controller Connection
• Fade: Color gradient, Press +- to change speed • On/off: Turn on/off all colors • +-: Bright intensity/speed control • RGBWAUV: static led colors (can press +/- to do the color mixing ) • 0-9 buttons: Built-in colors. • Sound: Sound modes press this to change. - Page 15 DMX channels in light. CH1>>RED, CH2>>GREEN, CH3>>RED+GREEN, CH4>>BLUE CH5>>RED+BLUE CH6>>BLUE+GREEN CH7>>RED+BLUE+GREEN SD Wireless 1-1. About the wireless, the different transmitter means different wireless frequency. for example, if you have 20 units transmitter(transmitter1, transmitter2..transmitter20),then you will have 20 wireless frequency, you can divide the battery par into 20 groups and control them separately without interference.
-
Page 16: Specification
please Go to “unpair” function, then switching by the up and down buttons for one time, for example, from Yes to No, or from No to Yes, for about 3 seconds, the pairing will be unpair, but it can only remove the pairing between itself and transmitter. - Page 17 • Running time : 200 Mins (full color), 13 hours (single color),7.5 hours(Auto) Effects • Dimming: 0-100%. • Strobe: 1-20 Hz. Control • Control mode: DMX512 Wireless( Default GZ wireless, Option SD), Master- Slave, Auto, IR, App • DMX Channels: 2 / 6 / 8 / 11 CHs •...
- Page 18 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
