- Page 1 Focus Beam200 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual Please read the instructions carefully before use...
-
Page 2: Table Of Contents
INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.SAFETY INSTRUCTION................2 4.INSTALLATION ..................4 5.TECHNICAL SPECIFICATION..............8 6.PANEL OPERATION ................9 7.CHANNEL DESCRIPTION ..............20 8.TROUBELSHOOTING ................24 9.CLEANING AND MAINTENANCE ............25... -
Page 3: Statement
1.STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction & problem owing to ignore the manual. -
Page 4: Preventing Electric Shock
Review the following safety precautions carefully before installing or operating the fixture. This fixture must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock WARNING! Risk of electric shock. -
Page 5: Avoid Personal Injury
Avoid personal injury WARNING! Take measure to prevent personal injury. Do not look directly at the light source from close range. Take precautions to prevent injury due to falls when working at height. For permanent installation, ensure that the fixture is securely fastened to ... -
Page 6: Dmx-512 Control Connection
mounting this fixture to truss be sure to sere to secure an appropriately rated clamp to the included Omega Bracket using a M10 screw fitted through the center hole of the ‘omega bracket’. As an added safety measure be sure to attached at least one properly rated Safety Cable to the fixture using one of the safety cable rigging point integrated in the base assembly. -
Page 7: Dmx-512 Connection With Dmx Terminator
DMX-512 connection with DMX terminator: For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain. -
Page 8: Dmx Address Setting
DMX Address Setting: By using a universal DMX controller to control the units, you will need to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button up to when the DMX Address is showing on the display. Pressing the ENTER button and the display will blink. -
Page 9: Technical Specification
bad contact. 5.TECHNICAL SPECIFICATION Power Supply - Voltage:AC110-240V,50/60Hz - Power:350W Light Source - Light source: 200W LED, Strip light : RGB LED Strip - LED life: 50000 hours Protocols - Control mode: DMX512, master-slave operation, auto control - Channel mode: 18CH - Support RDM function, DMX software upgrade function Display/Case/Base - Display mode: LCD display, lamp temperature display, Chinese and English... -
Page 10: Panel Operation
- 8 and 8+8+8 facet prism with bi-direction rotating Movement - Pan: 540 degree + fine - Tilt: 270 degree + fine Dimmer/Strobe - Dimming level: 0-100% perfect linear dimming system - Strobe: 1-25 Hz Synchronous pulse strobe, random pulse strobe IP Rated - IP20, indoor only Weigh &... -
Page 11: Operation
RDM protocol is embed in fixture, user set DMX address via cable using the controller support RDM function. when fixture was search by controller, displayer will echo ‘RDM’ indicate this RDM is work. “LEFT” and “RIGHT” keys: Return to top level. ... -
Page 12: Parameter Value Setting
value, finally, Press encoder button/key one again to save value or setting 6.2.2 Parameter value setting When the selected item is value need to been modified, the dialog shown in below will popup. Modify value: Can quickly modify value via pull the slider to the desired ... -
Page 13: Operation And Parameter Instruction
6.2.4 Sub Menu (Parameter) 6.3 Operation and parameter instruction Chick item of main menu, enter corresponding sub menu shown in Figure 6, In main menu, chick 1/6 function button into corresponding parameter menu. In sub menu(page), chick main item on the left side of displayer, can shift to corresponding sub menu(page) quickly. - Page 14 6.3.1. DMX address setting Enter page , can set fixture DMX address, channel mode and so on.The menu settings of fixture have optimized the setting of addresses. Several settings of the address are as follows: Select " Prev " or "Next", the fixture will be based on the current address and ...
-
Page 15: Set Display
Master and slave selection, non-DMX mode takes effect, select the mode of data output, fixture detect DMX cable state automatic switch output, prevent data conflicts fixture runs built-in program. If DMX has no signal, it outputs data Master (synchronization), otherwise it does not output data. Choose Slave Fixture runs built-in program and do not output data... - Page 16 Keep the last operation page Mode1 Black Black screen, showing the address code of the current fixture in the Mode2 lower left corner. Mode3 Display trademark information, address code and operation mode. Set the display direction of the screen. No reverse display Screen Reverse display Automatically detect the direction of lamps and automatically switch...
-
Page 17: Set Light Run Parameter
6.3.4 Scene Enter the page shown in below, and the fixture enters the scene editing mode. Under this page, the fixture does not receive DMX console data, and the edited data will effect on the fixture immediately. The content of the page depends on the currently selected channel mode, and the channel content and order displayed are consistent with the fixture channel table. - Page 18 Set the rotation direction of PAN Pan Invert Set the rotation direction of TILT Tilt Invert Setting up fixture to detect XY lost step and correct Uncorrected position after out of step P/T Rectify After losing step, the position is automatically corrected and the out of step fault is recorded.
-
Page 19: Status And Information
Factory Pop up the confirmation box, select "SURE", and return the lamp parameters Setting to the factory settings. When choosing power-on mode, the lamp will wait for 30 seconds after power-on, let the lamp fully start, internal voltage is stable enough, then start the reset program, if the field capacity is stable, recommend power-on mode. - Page 20 Error Logging Total number of failures detected after power on 12::03 The time of power failure when the fault occurs is in minutes. The effective hall signal is not detected when the motor is Hall error reset When the motor is reset, the hall signal of the motor is always Hall short effective No effective optocoupler signal is detected when the motor is...
-
Page 21: Channel Description
The type of fixture is the same as the model information of Model RDM. Panel Firmware version and serial number of display panel Main Board Firmware version and serial number of mother board 1 Light Record the total cumulative time of light source opening, unit minute, user time manual cleaning, as a reference for regular maintenance of light source time The total accumulated time for recording the opening of fixture is not allowed to... - Page 22 65-69 Colour6+colour7 70-74 Colour7 75-79 Colour7+colour8 80-84 Colour8 85-89 Colour8+colour9 90-94 Colour9 95-99 Colour9+colour10 100-104 Colour10 105-109 Colour10+colour11 110-114 Colour11 115-119 Colour11+colour12 120-124 Colour12 125-129 Colour12+colour13 130-134 Colour13 135-139 Colour13+colour14 140-144 Colour14 145-149 Colour14+white 150-202 Clockwise water flow effect. Fast to slow 203-255 Counter-clockwise water flow effect.
- Page 23 10-14 Gobo 2 15-19 Gobo 3 20-24 Gobo 4 25-29 Gobo 5 30-34 Gobo 6 35-39 Gobo 7 40-44 Gobo 8 45-49 Gobo 9 50-54 Gobo 10 55-59 Gobo 11 60-64 Gobo 12 65-69 Gobo 13 70-128 Clockwise water flow effect. Fast to slow 129-131 Stop 132-190...
- Page 24 0-127 None Prism1 128-255 Prism1 inserted 0-127 None Prism2 128-255 Prism2 inserted 0-127 0-360degrees 128-190 Clockwise water flow effect. Fast to slow Prism rotation 191-192 Stop 193-255 Counter-clockwise water flow effect. Slow to fast 0-127 Rainbow-Frost 128-191 Rainbow inserted 192-255 Frost inserted Focus 0-255...
-
Page 25: Troubelshooting
8.TROUBELSHOOTING Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connect power and main fuse. 2. -
Page 26: Cleaning And Maintenance
1. Make sure the unit does not receive DMX signal.. 2. Check microphone to see if it is good by tapping the microphone. F. If The tilt belt is broken 1. The stepper motor might be damaged or the cable connected to the PCB is broken. - Page 27 Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized service technician. Should you need any spare parts, please order genuine parts from your local dealer.
- Page 28 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
