This product manual contains important information about the safe
installation and use of this projector. Please read and follow these
instructions carefully and keep this manual in a safe place for future
reference.
User manual
Please read the instructions carefully before use
Glow Par9 IP
（Quad-Color LED）
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RIUKOE Glow Par9 IP
Summary of Contents for RIUKOE Glow Par9 IP
- Page 1 Glow Par9 IP （Quad-Color LED） This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Information....................2 2. IP65 Rated ......................3 3. Connecting to a DMX control device ..............4 4. Configuring the fixture for DMX control ............... 5 5. Cleaning ........................ 5 6. DMX Channel ....................... 6 7. Control menu ......................7 8. -
Page 3: Safety Information
STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 4: Avoid Personal Injury
Install in a location that prevents accidental contact with the fixture. ⚫ Install only in a well-ventilated space. ⚫ Install only in accordance with applicable building codes. ⚫ Do not paint, cover or modify the fixture. ⚫ Keep all flammable materials away from the fixture. ⚫... -
Page 5: Connecting To A Dmx Control Device
define the degree of protection. The first digit (Foreign Bodies Protection) indicates the extent of protection against particles entering the fixture and the second digit (Water Protection) indicates the extent of protection against water entering the fixture. An IP65 rated lighting fixture is one, which has been designed and tested to protect against the ingress of dust (6) and high-pressure water jets from any direction (5). -
Page 6: Configuring The Fixture For Dmx Control
4. Configuring the fixture for DMX control About DMX The fixture can be controlled using signals sent by a DMX controller on a number of channels (which varies depending on the DMX mode that has been set). The first channel used to receive data from a DMX control device is known as the DMX start address. -
Page 7: Dmx Channel
installation should therefore be checked at frequent intervals within the first few weeks of operation to see whether cleaning is necessary. This procedure will allow you to assess cleaning requirements in your particular situation. Clean the fixture using a soft cloth dampened with a solution of water and a mild detergent. -
Page 8: Control Menu
151-200 Jump, gradual and pulse variable effect 201-255 Sound control Speed 0-255 Slow →fast 7. Control menu Display: MENU To select the programming functions To go forward in the selected functions DOWN To go backward in the selected functions ENTER To confirm the selected functions OPERATING INSTRUCTION Press "Menu"... - Page 9 DISPLAY FUNCTION 5 Channel address code, (001-512) d001 B, C key to add and subtract address code values 9 Channel address code, (001-512) d.001 B, C key to add and subtract address code values Color jump to change, (01-99) CC01 B, C key to modify jump to change speed Gradient (01-99) CP01...
-
Page 10: Specification
8. Specification Electronic Power supply: Electronic auto-ranging Input voltage range: supply 100-240V, 50/60Hz Power consumption 200W Fuse T2.5A 250V Light Sources LED: 9 x 12W LEDs (RGBW) LED life: 50000 hrs Beam angle: 25° Control DMX Channel: 5/9 Channel Control Modes: DMX512/Master-slave/Auto Construction Display: 4 push button menu with LED display Data In/Out socket: 3-pin XLR sockets... - Page 11 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
