9x12W RGBWA-UV 6IN1 LED Battery Par
This product manual contains important information about the safe
installation and use of this projector. Please read and follow these
instructions carefully and keep this manual in a safe place for future
reference.
User manual
Please read the instructions carefully before use
PL-WT009B-IP65
Advertisement
Table of Contents
Related Manuals for RIUKOE PL-WT009B-IP65
Summary of Contents for RIUKOE PL-WT009B-IP65
- Page 1 9x12W RGBWA-UV 6IN1 LED Battery Par PL-WT009B-IP65 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Information....................2 2. IP65 Rated ......................3 3. Connecting to a DMX control device ..............4 4. Configuring the fixture for DMX control ............... 5 5. Cleaning ........................ 5 6. DMX Channel ....................... 6 7. Control menu ......................7 8. -
Page 3: Safety Information
STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 4: Avoid Personal Injury
Install in a location that prevents accidental contact with the fixture. ⚫ Install only in a well-ventilated space. ⚫ Install only in accordance with applicable building codes. ⚫ Do not paint, cover or modify the fixture. ⚫ Keep all flammable materials away from the fixture. ⚫... -
Page 5: Connecting To A Dmx Control Device
define the degree of protection. The first digit (Foreign Bodies Protection) indicates the extent of protection against particles entering the fixture and the second digit (Water Protection) indicates the extent of protection against water entering the fixture. An IP65 rated lighting fixture is one, which has been designed and tested to protect against the ingress of dust (6) and high-pressure water jets from any direction (5). -
Page 6: Configuring The Fixture For Dmx Control
4. Configuring the fixture for DMX control About DMX The fixture can be controlled using signals sent by a DMX controller on a number of channels (which varies depending on the DMX mode that has been set). The first channel used to receive data from a DMX control device is known as the DMX start address. -
Page 7: Dmx Channel
schedules will vary depending on the operating environment, and the installation should therefore be checked at frequent intervals within the first few weeks of operation to see whether cleaning is necessary. This procedure will allow you to assess cleaning requirements in your particular situation. Clean the fixture using a soft cloth dampened with a solution of water and a mild detergent. -
Page 8: Control Menu
Strobe Strobe off 10-255 Strobe speed adjustment No function 10-50 Auto Jump 51-100 Auto Fade 101-150 Auto Pulse 151-200 Auto Combined 201-255 No function 1-255 Speed of Auto programs 7. Control menu Display: OPERATING INSTRUCTION Press "Menu" to "Set DMX Address", and press "ENTER" keys to enter into Show "Set DMX Address DMX Address:001",Press the "UP and DOWN"... - Page 9 save and Exit Level 1 Level 2 Level 3 Description 6 channel DMX mode Channel 10ch 10 channel DMX mode DMX address 000-512 DMX Address Setting W-DMX On/Off Turn Wireless DMX on or off Setting DMX Setting W-DMX 1ch-7ch FREQ Channel List 6 channel DMX mode list 10ch...
-
Page 10: Specification
R/G/B/W/A/ all color manual dimmer (0-255) Manual dimming Strobe Master strobe speed(0-99) Clear Clear manual dimmer value to 000 Static Color C1-C36 Select static colour mode Manual Color Jump mode. Adjustable speed (0- Jump Control Color Fade mode. Adjustable speed (0- Fade Auto Color Pulse mode. - Page 11 Photometrics • Light Source: 9x 12W RGBWA UV LEDs. • Beam Angle: 25°. • PWM: 20,000 Hz • LED Lifespan: 50,000 hours. Effects • Dimming: 0-100%. • Strobe: 1-20 Hz. Control • Control mode: DMX512, 2.4G Wireless DMX,IR • DMX Channels: 6 / 10. •...
- Page 13 Add: No.619 Building C Jiahua Square Yingbin Avenue Guangzhou China +86-20-2904 6476 info@ricostagelight.com YouTube www.riukoe.com Facebook...
