This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
B-Eye 1940 IP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B-Eye 1940 IP and is the answer not in the manual?

Questions and answers

Related Manuals for RIUKOE B-Eye 1940 IP

Summary of Contents for RIUKOE B-Eye 1940 IP

  • Page 1 B-Eye 1940 IP This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.IP65 RATED ....................2 4.SAFETY INSTRUCTION................3 5.INSTALLATION ..................5 6.TECHNICAL SPECIFICATION..............8 7.PANEL OPERATIONS ................10 8.CHANNEL DESCRIPTION ..............12 9. TROUBLE SHOOTING ................21 10.LEANING AND MAINTENANCE ............22...

  • Page 3: Statement

    1.STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction & problem owing to ignore the manual.

  • Page 4: Safety Instruction

    second digit (Water Protection) indicates the extent of protection against water entering the fixture. An IP65 rated lighting fixture is one, which has been designed and tested to protect against the ingress of dust (6) and high-pressure water jets from any direction (5). Please note although this fixture is IP rated, the fixture is NOT suitable for marine and/or coastal environment installations.

  • Page 5: Preventing Burns And Fire

    Ensure that the fixture is electrically connected to earth (ground).  Do not apply power if the fixture is in any way damaged.  Do not immerse the fixture in water or liquid.  Preventing burns and fire WARNING! Take measures to prevent burns and fire. Install in a location that prevents accidental contact with the fixture.

  • Page 6: Installation

    5.INSTALLATION The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight.

  • Page 7: Dmx-512 Control Connection

    DMX-512 control connection: Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other side to the male 3-pin XLR input of the moving head. You can chain multiple Moving head together through serial linking. The cable needed should be two core, screened cable with XLR input and output connectors.

  • Page 8: Dmx-512 Connection With Dmx Terminator

    DMX-512 connection with DMX terminator: For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain.

  • Page 9: Technical Specification

    Please refer to the following diagram to address your DMX512 channel for the first 4 units： CHs Mode Unit 1 Adds Unit 2 Adds Unit 3 Adds Unit 4 Adds 18CH 21CH 35CH 78CH 94CH 111CH 6.TECHNICAL SPECIFICATION Power Supply - Voltage:AC100-240V,50/60Hz - Power:820W Light Source...
  • Page 10 Zoom - Zoom system: linear electric zoom - Zoom angle: 4 ° to 55 ° Effect macros - static effect macro function and dynamic effect macro function Lens rotation - Optical lens with 360 ° infinite rotation, automatic error correction function for rotation, variable kaleidoscope, small waist and other effects Strobe - Pulse strobe, strobe speed 1-25 times per second...

  • Page 11: Panel Operations

    Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. 7.PANEL OPERATIONS Display Setting Main Menu Second Third Fourth Dmx Address 000 - 512 18CH / 21CH / 35CH / 78CH / 94CH / Dmx Mode 111CH Run Mode...
  • Page 12 Pan Fine 000 - 255 Tilt 000 - 255 Tilt Fine 000 - 255 ⁞ ⁞ Current Time xxxH Time Total Time xxxH Power Count xxxx Pan 、 Tilt 、 Zoom 、 ZoomRo 、 Sensor Temp/All Sensors Are ok! Information Head Temp xxxC Temperature...

  • Page 13: Channel Description

    White 000 - 255 Motor Reset Cance / Run Fixture Reset Factory Cance / Run Language CH / EN Display Flip Normal / Reverse Display Display Mode 60s / Show Screensaver Close / Open ▲▲▲▼▼▼ Temp Unit C / F 8.CHANNEL DESCRIPTION This luminaire channel can be viewed in scene mode in order, channel mode is set in the "Address Settings"...
  • Page 14 Counterclockwise rotation, Slow to 193 - 255 fast 0 - 255 Stobe 0 - 3 Close 4 - 103 Rule Strobe, slow to fast 104 - 107 Open 108 - 207 pulse Strobe, slow to fast Strobe 208 - 212 Open 213 - 225 Random strobe ,Slow speed...
  • Page 15 Macro 0 - 255 Macro Effect Effect Close Effect Dynamic effect, one effect every 5 1 - 255 values Effect Speed 0 - 255 Effect Speed 0 - 250 Empty Reset Motor reset (value remains 251 - 255 unchanged for 5 seconds) Red1 0 - 255 Red1...
  • Page 16 White4 0 - 255 White4 Red19 0 - 255 Red19 Green19 0 - 255 Green19 Blue19 0 - 255 Blue19 White19 0 - 255 White19 21/78 CH 21CH 78CH Name Value Function 0 - 255 Red Fine 0 - 255 Red Fine Green 0 - 255...
  • Page 17 196 - 223 3600K 224 - 251 3200K 252 - 255 2800K Macro 0 - 255 Macro Stobe 0 - 3 Close 4 - 103 Rule Strobe, slow to fast 104 - 107 Open 108 - 207 pulse Strobe, slow to fast Strobe 208 - 212 Open...
  • Page 18 191 - 192 Stop Counterclockwise rotation, Slow to 193 - 255 fast Red1 0 - 255 Red1 Green1 0 - 255 Green1 Blue1 0 - 255 Blue1 Red2 0 - 255 Red2 Green2 0 - 255 Green2 Blue2 0 - 255 Blue2 Red3 0 - 255...
  • Page 19 Blue Fine 0 - 255 Blue Fine White 0 - 255 White White Fine 0 - 255 White Fine Empty 10 ~ 27 8500K 28 - 55 7500K 56 - 83 6800K 84 - 111 6200K 112 - 5600K 140 - 5000K 168 - 4500K...
  • Page 20 208 - Open 213 - Random strobe ,Slow speed 226 - Random strobe ,Middle speed 239 - Random strobe ,Fast speed 252 - Open 0 - 255 Dim Fine 0 - 255 Dim Fine 0 - 255 PanFine 0 - 255 PanFine Tilt 0 - 255...
  • Page 21 Shape Selection 0 - 255 Shape Selection Shape Speed 0 - 255 Shape Speed Shape Fade 0 - 255 Shape Fade 0 - 255 Shape Red Shape Red 0 - 255 Shape Green Shape Green 0 - 255 Shape Blue Shape Blue 0 - 255 Shape White...

  • Page 22: Trouble Shooting

    Blue4 0 - 255 Blue4 White4 0 - 255 White4 Red19 0 - 255 Red19 Green19 0 - 255 Green19 Blue19 0 - 255 Blue19 White19 0 - 255 White19 9. TROUBLE SHOOTING Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A.

  • Page 23: Leaning And Maintenance

    C. One of the channels is not working well 1. The stepper motor might be damaged or the cable connected to the PCB is broken. 2. The motor’s drive IC on the PCB might be out of condition. D. The lamp is cutting out intermittently 1.
  • Page 24 Frequent cleaning is recommended to insure proper function, optimized light output, and an extended life. The frequency of cleaning depends on the environment in which the fixture operates: damp, smoky or particularly dirty environments can cause greater accumulation of dirt on the fixture’s optics. Clean the external lens surface at least every 20 days with a soft cloth ...
