RIUKOE Hybrid BSW400 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Hybrid BSW400
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hybrid BSW400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RIUKOE Hybrid BSW400

Summary of Contents for RIUKOE Hybrid BSW400

  • Page 1 Hybrid BSW400 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.SAFETY INSTRUCTION................2 4.INSTALLATION ..................4 5.TECHNICAL SPECIFICATION..............8 6.PANEL OPTATION ................. 12 7.CHANNEL DESCRIPTION (23CHS) ............20 8.TROUBELSHOOTING ................25 9.CLEANING AND MAINTENANCE ............26...

  • Page 3: Statement

    1.STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction & problem owing to ignore the manual.

  • Page 4: Preventing Electric Shock

    Review the following safety precautions carefully before installing or operating the fixture. This fixture must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock WARNING! Risk of electric shock.

  • Page 5: Avoid Personal Injury

    Avoid personal injury WARNING! Take measure to prevent personal injury. Do not look directly at the light source from close range.  Take precautions to prevent injury due to falls when working at height.  For permanent installation, ensure that the fixture is securely fastened to ...

  • Page 6: Dmx-512 Control Connection

    Omega Bracket using a M10 screw fitted through the center hole of the ‘omega bracket’. As an added safety measure be sure to attached at least one properly rated Safety Cable to the fixture using one of the safety cable rigging point integrated in the base assembly.

  • Page 7: Dmx-512 Connection With Dmx Terminator

    DMX-512 connection with DMX terminator: For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise.
  • Page 8 Please refer to the following diagram to address your DMX512 channel for the first 4 units： CHs Mode Unit 1 Adds Unit 2 Adds Unit 3 Adds Unit 4 Adds 23CH Precautions for using RDM： RDM is an extended version of the DMX512-A protocol. It is a remote device management protocol.

  • Page 9: Technical Specification

    5.TECHNICAL SPECIFICATION Power Supply - Voltage:AC110-240V,50/60Hz - Rated Power:500W Light Source - Light source : 400W - Color temperature：8000K - Light source life: 20000h - Lumen illuminance: 5 meters 120,000 lm - Beam angle: 4 °-35 ° Protocols - Control mode: DMX512/Master-Slave/Auto run/ RDM - Channel mode: 23 CHs Display - Display mode: LCD display, key + touch dual operation mode...
  • Page 10 Patterns - Static pattern: 12 fixed patterns + white light - Rotation pattern: 7 glass patterns Prisms - Standard single 6+8 facet prism with bi-direction rotating Focus - Focusing system: linear adjustment from 4 meters to 50 meters - Atomization system: 1 independent atomization effect, soft and natural light spot Movement - Pan: 540 (16bit) degree + fine, electronic error correction...
  • Page 11 Drawing...
  • Page 12 Color Wheel Fixed Gobo Wheel Rotating Gobos CMY Filter Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice.

  • Page 13: Panel Optation

    6.PANEL OPTATION 6.1 Brief The light panel diagram show as Figure 3, Left area is TFT Displayer, support touch, and right area is KEY, both of touch and KEY can operate light and setting. Display & operation just like ‘Android operation system’ , touch the item will set or modify setting.
  • Page 14 4 will popup. Figure 2 Dialog of value setting Modify value：Can quickly modify value via pull the slider to the desired  position, or click the button of ‘up’ or ‘down’ whit finger on the right side to set the exact desired value, another way is roll encoder on the right hand side of panel.
  • Page 15 Figure 3 Dialog of confirm 6.2.4 Sub Menu (Parameter) Chick item of main menu, enter corresponding sub menu, shown in Figure 6, total 6 sub menu, includes class of parameter and status:  ADDRESS：Set light DMX address.  WORKMOD：Set light work mode, master or slave mode when in auto run mode.
  • Page 16 to corresponding sub menu(page) quickly. 6.3.1 ADDR--> Address: Set DMX Address Click and select the "ADDR", can enter the page of DMX address setting, range from 1 to 512, the address code shouldn’t is not greater than (512- channels quantity), otherwise the light will not been controlled.
  • Page 17 Figure 6 page of work mode  DMX Ctrl: Choose to set DMX Mode,  Auto Run: Choose to set Auto Mode,  Sound Ctrl: Choose to set Sound Mode,  M/S Choose: Available just in ‘AUTO RUN’ or ‘SOUND Ctrl’ mode. ON-->...
  • Page 18 Figure7 page of display  Language: English / 中文.  Screen Saver: when panel is idle(these is no operation in 10 second), displayer will enter saver status OFF--> No screen saver. Mode1--> Power-saving mode, turn off the display. Mode2--> Displays the current address. Mode3-->...
  • Page 19 Figure 8 page of Test  PAN: range for 0 to 255;  TILT: range for 0 to 255;  FOCUS: range for 0 to 255;  COLOR: range for 0 to 255;  GOBO: range for 0 to 255; ...
  • Page 20 Figure 9 page of run parameter  Pan Invert: Reverse PAN move OFF--> Pan Normal move.(Default) ON--> Reverse PAN move.  Tilt Invert: Reverse TILT move OFF--> Tilt Normal move.(Default) ON--> Reverse Tilt move.  P/T Rectify: Disable or enable position rectify function OFF-->...

  • Page 21: Channel Description (23Chs)

    Figure 10 page of status  Work Mode: Show the current working mode.  Address: Show the current address.  Version: Show the version of the lamp.  Elapse: Working hours after turn on.  Total: Cumulative hours of operation 7.CHANNEL DESCRIPTION (23CHs) 23CH FUNCTION...
  • Page 22 4-103 Slow strobe to fast strobe 104-107 White 108-207 Slow strobe to fast strobe (mode 2) 208-212 White 213-251 Free strobe 252-255 White White 10-19 Color 1 20-29 Color 2 30-39 Color 3 40-49 Color 4 COLOR 50-59 Color 5 60-69 Color 6 70-79...
  • Page 23 216-220 Stop 221-255 Slow to fast negative rainbow 0-255 0-100% CH10 0-255 0-100% CH11 0-255 0-100% CH12 0-255 0-100% White Gobo 1 10-14 Gobo 2 15-19 Gobo 3 20-24 Gobo 4 25-29 Gobo 5 30-34 Gobo 6 35-39 Gobo 7 40-44 Gobo 8 CH13...
  • Page 24 95-99 Gobo 7 shaking slow to fast 100-104 Gobo 8 shaking slow to fast 105-109 Gobo 9 shaking slow to fast 110-114 Gobo 10 shaking slow to fast 115-119 Gobo 11 shaking slow to fast 120-127 Gobo 12 shaking slow to fast 128-190 Fast to slow positive rainbow 191-192...
  • Page 25 140-149 Shake slow to fast GOBO7 150-199 Rotate forward (fast to slow) 200-255 Rotate reverse (slow to fast) 0-127 0-360 degrees 128-187 Rotate forward (fast to slow) GOBO CH17 ROTATING 188-195 Stop 196-255 Rotate reverse (slow to fast) 0-127 Close CH18 PRISM 1 128-255...

  • Page 26: Troubelshooting

    8.TROUBELSHOOTING Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connect power and main fuse. 2.

  • Page 27: Cleaning And Maintenance

    1. Make sure the unit does not receive DMX signal.. 2. Check microphone to see if it is good by tapping the microphone. F. If The tilt belt is broken 1. The stepper motor might be damaged or the cable connected to the PCB is broken.
  • Page 28 Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized service technician. Should you need any spare parts, please order genuine parts from your local dealer.
  • Page 29 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
