Intense TRACER 279 PRO Manual page 21

E F
G E O M E T R Y
FLIP CHIP...
CONTINUED
STEP 04
Remove the two D-Lock Shoulder Bolts (E) and pull
the Top Link forward and carefully remove the silver
spacers (F).
STEP 05
In order for the Rear Triangle to move more freely pull
the rear brake hose and rear derailleur cable through
the frame by roughly 50mm/2" (G). This will allow the
rear end of the frame to drop down slightly, giving you
easy access to the Shock Bolt and Flip Chips (H).
G H
40 41
