Summary of Contents for Intense Spider 275 CARBON BOOST

  • Page 1 275 CARBON BOOST...
  • Page 2 From the early days of Intense, when founder Jeff Steber worked alone in his garage to today, where a crew of talented people work in a Temecula, CA factory, Intense has been...

  • Page 3: Table Of Contents

    introduction / registration frame features / component spec Geometry exploded view and b.o.m. Assembly torque chart setup maintenance I N T E N S E C Y C L E S...

  • Page 4: Frame Features / Component Spec

    frame frame Features // • Adjustable Travel: 4.5" to 5" (115mm-130mm) • 27.5” Wheel size features / • Integrated BOOST 148 x 12 dropouts • 5.96 lbs / 2,705 grams = Standard frame w/ alloy link, no shock • 4.48 lbs / 2,490 grams = SL Super Light frame w/ carbon link, no shock •...

  • Page 5: Geometry

    Geometry SMALL MEDIUM LARGE XLARGE Wheel Base: 1125 mm/ 44.3” 1152 mm/ 45.4” 1178 mm/ 46.4” 1203 mm/ 47.4” GEOMETRY NOTEs Top Tube Length: 572 mm/ 22.5” 597 mm/ 23.5” 622 mm/ 24.5” 648 mm/ 25.5” GEOMETRY TAKEN AT TOP OUT WITH 519MM Chain Stay Length: 419 mm/ 16.5”...

  • Page 6: Exploded View And B.o.m

    exploded view and b.o.m. s p i d e r 2 7 5 C a r b o n b o o s t...
  • Page 7 ITEM PART ITEM PART ITEM DESCRIPTION QTY. TORQUE SPEC. ITEM DESCRIPTION QTY. TORQUE SPEC. NUMBER NUMBER Derailleur Mount 5 Nm / 130209 For Single Ring Setip Zerk Fitting 401011 M6 x 1.0 Cover 40 in-lbs Bottle Mount Bolt, 6 Nm / Crush Tube 130759 Top Link Bearing Crush Tube...

  • Page 8: Assembly

    It is always recommended to use an authorized Intense dealer for service and maintenance. Always wear eye protection. It is critical to use the proper tools, loctite, grease and torque specs during assembly. Failure to follow these instructions may result in serious bodily injury or death.
  • Page 9 C O N N E C T I N G T O P L I N K T O F R O N T T R I A N G L E // C O N N E C T I N G B O X L I N K T O F R O N T T R I A N G L E // Holding top link (#130760) with shock Using upper pivot axle (#130780), insert Hold bearing caps with rounded ends...
  • Page 10 C O N N E C T I N G R E A R T R I A N G L E C O N N E C T I N G R E A R T R I A N G L E T O B O X L I N K // T O T O P L I N K // Follow previous step to connect rear...
  • Page 11 125 in/lbs (IMAGE #16). adjustable travel NOTE the top link of the spider 275 carbon boost features dual mounting positions. The Upper shock mounting hole on top link is for LONG travel, the lower hole is for SHORT travel. for more information see the set up guide on page 14.
  • Page 12 INSTALLING ADJUSTER CONES ON LOWER LINK // INSTALLING DERAILLEUR HANGER // Grease and install adjuster cone Torque M6x22mm (#410032) to 14 NM Grease outer edges of derailleur Insert hanger (#130790) into back of (#130807) into head of main pivot bolt or 125 in/lbs (IMAGE #19).

  • Page 13: Torque Chart

    torque chart 7 Nm / 60 in-lbs 20 Nm / 175 in-lbs 7 Nm / 60 in-lbs M8 HEX 7 Nm / 60 in-lbs M5 HEX 14 Nm / 125 in-lbs torque Achieving proper torque is vital to ensuring the safe performance and function of the spider 275 carbon boost frame.

  • Page 14: Setup

    set up upper mount lower mount seatpost adjustable travel make sure to insert seat post at least upper mount: 130mm 4” into the main frame. Anything less lower mount: 115mm than this amount could cause damage to the frame or even failure. s p i d e r 2 7 5 C a r b o n...

  • Page 15: Shock Setup

    Travel 115 mm 130 mm shock setup Shock Stoke 50 mm Shock Sag 30% when sitting on the bike Fork Sag 25-30% when sitting on the bike rock shox monarch rt3 200x50mm SHOCK Rock Shox Monarch RT3 200x50mm RIDER WEIGHT(LBS/KGS) SPRING (PSI) REBOUND (clicks out) SPRING (PSI)
  • Page 16 Travel 115 mm 130 mm shock setup Shock Stoke 50 mm Shock Sag 30% when sitting on the bike Fork Sag 25-30% when sitting on the bike x-fusion 02 rl 200x50mm SHOCK X-Fusion 02 RL 200x50mm RIDER WEIGHT(LBS/KGS) SPRING (PSI) REBOUND (clicks out) SPRING (PSI) REBOUND (clicks out)
  • Page 17 I N T E N S E C Y C L E S...

  • Page 18: Maintenance

    • Never clamp any part of a carbon frame in a bike stand or car rack. • Always inspect your frame if you experience any chain suck. Intense frames come equipped with steel chain suck plates but damage can still be done in the event of chain suck.

  • Page 19: Maintenance Schedule

    maintenance Schedule* 500 Miles or 2000 Miles or 6 4000 Miles or Action Every Ride 1 Month Months 1 Year Tires Check air pressure, inspect tread and sidewalls for tears and punctures Chain Brush off and lubricate Brakes Squeeze brakes and confirm function General Clean complete bike of mud and debris Headset...
  • Page 20 w w w . I N T E N S e C Y C L E S . c o m p h o n e : (9 5 1) -2 9 6 - 9 5 9 6 C u s t o m e r S e r v i c e : c s @ i n t e n s e c y c l e s . c o m G e n e r a l I n f o : i n f o @ i n t e n s e c y c l e s .
