F
S T E P 4 C O N T I N U E D . . .
Once everything is lined up and in position, reinsert
the axle and tighten using the integrated lever on the
non-drive side (left), turning clockwise until tight (F).
Reinstall the lever within the axle by pushing it firmly
back in place. Then with a 5mm Allen key on the drive
side of the bike tighten the axle to 11Nm (G).
You can now take the lock off your SRAM rear
derailleur (H). To do this, gently push the derailleur
cage forward a little, the lock will automatically
release, slowly let the derailleur arm move backward
into position.
G H
20 21
