BOB REVOLUTION SE Owner's Instruction Manual page 41

WEATHER SHIELD
The Weather Shield is available as an
accessory and not included in your
box.
When using the Weather Shield,
rear fl ap must be positioned
accordingly to ensure proper air
fl ow to child.
1. Adjust Seat Position
Pull seat recline straps to raise
seat back into upright position.
2. Stow Window Cover
Stow window cover in pocket to
expose canopy straps.
3. Pull Canopy Straps
Pull canopy straps and secure
to Velcro strips on back of
canopy.
4. Store Canopy
Position rear canopy stay
against handlebar and fold
canopy fl ap up and over
canopy, connecting Velcro
strips. Inspect opening at back
of stroller to make sure space
between top of seat back and
canopy is unobstructed.
After installing Weather
Shield, confi rm vents on
Weather Shield are
aligned with space
above seat back and all
other vents are free of
obstruction.
40
2000008437 – 09/12
