BOB REVOLUTION SE Owner's Instruction Manual page 35

Infl ating tires above 2 bar can
damage the wheel and/ or tire
resulting in loss of control and
injury.
Aluminum wheels can have the tires
infl ated to the pressure embossed on
the tire. However, we recommend 2
bar for a comfortable ride.
Infl ating tires above the maximum
infl ation pressure embossed on the
tire can damage rim and or tire
resulting in loss of control and
injury.
ADJUST TRACKING
If stroller pulls left or right when the
front wheel is in Off-Road mode and
stroller is on fl at terrain, adjust
tracking as outlined in the following
steps.
Do not roll test with a child or any
occupant in the stroller.
1. Empty Stroller
Remove contents from low boy cargo
basket and pockets.
2. Check Tire Pressure
3. Set Stroller to Off-Road Mode
Slide swivel knob to right. Knob will
slide into downward position. Rotate
fork/wheel until it "snaps" into
forward position. See Choose Walk
or Off-Road Mode section.
4. Place Stroller On Level Ground
Find a stretch of level ground about 5
meter long.
5. Align Rear Wheel Axles
Align stroller so rear wheel axles are
perpendicular to a straight line.
6. Test Alignment
Push stroller straight forward and
release to see if stroller veers right or
left. Repeat push test several times.
If stroller consistently pulls to left or
right, proceed to Fine Tune Tracking.
FINE TUNE TRACKING
If Stroller Pulls LEFT
If your stroller pulls LEFT, turn
tracking knob counterclockwise up to
one half turn.
Tracking Knob
5 meter
34
2000008437 – 09/12
