CETECOM Inc.
Test report no.:EMC_381EN489-17_2002

EMISSION TEST:

RADIATED EMISSIONS

This test assessses the ability of ancilliary equipment to limit their internal noise from being radiated from the enclosure.
According to EMC basic standard (EN 55022)
Measurement according to EMC basic standard, but performed in the anechoic chamber with a reduced measuring distance of
3m. The reduction of the measuring distance and the existing floor absorber are corrected with the chamber factor (Method
Dr. Garn, Austrian Research Centre, Seibersdorf). The test results of the anechoic chamber correspond to the 10m-OATS
results
Test setup
EUT was setup in an anechoic chamber
Limits
Freq. Range
30MHz – 230MHz
230MHz – 1000MHz
EUT Type and
S/N or EUT set-up
no.
Plot receiving
No. antenna
directed to
1.1 --
Remarks: All measurements were carried out in peak mode. As long as the values stay under the average limit line
No QP measurements are carried out.
Issue date:2003-01-10
Set.
angle of polari-sation
turntable (h / v)
0 º - 360º h/v
Page 9 (25)
Limit (Quasi peak)
30dBµV/m
37dBµV/m
comment
(e.g. operating mode or
operating mode no.)
EUT operating mode 3
result
(passed /
failed)
Passed
