Rf Common Mode - Broadcom F5D7010CE2 Test Report

CETECOM Inc.
Test report no.:EMC_381EN489-17_2002 Issue date:2003-01-10 Page 14 (25)

RF COMMON MODE

According to EMC basic standard (EN 61000-4-6[10])
Start Frequency = 150KHz Stop Frequency = 80MHz
Frequency Step = 50KHz in the range of 150KHz – 5MHz
1% increment in the range of 5MHz – 80MHz
Field strength = 3V/m
Modulation = AM, 1KHz, 80%
Test setup
Injection via CDN or BIC clamp
Failure Criteria
Failure Criteria obesrved
Plot no. Injection on Injection Via Reaction of EUT during and after test Result
-- AC input power line CDN No reactions recognized N/A
Performace criteria A observed
Note: This test does not apply due to the fact that EUT's power suuply is host
dependant.
