CETECOM Inc.
Test report no.:EMC_381EN489-17_2002

AC LINE CONDUCTED EMISSIONS

According to EMC basic standard (EN 55022 [7] Class-B)
1.For the table top EUT the distance to the reference ground plane (wall) should be 40 cm.
2.AC input line plugged into LISN
EUT Operating mode
Tx at middle. channel
Plot no. Powerline
(L,N)
-- L+N
Note: This test does not apply due to the fact that EUT's power is host dependant.
Issue date:2003-01-10
EUT operating mode or
operating mode no.
Detector Additional (scan-) information
(Peak, (e.g. Pre-test Fastscan,
AV, QP) Maxhold,
Final measurement)
QP Final measurement
Page 10 (25)
Result
(passed /
failed )
N/A
