Electrostatic Discharge - Broadcom F5D7010CE2 Test Report

CETECOM Inc.
Test report no.:EMC_381EN489-17_2002

ELECTROSTATIC DISCHARGE

According to EMC basic standard (EN 61000-4-2[10])
For the table top EUT the distance to the reference ground plane should be 80 cm.
Direct contact discharge on conducting surfaces of EUT
Indirect air discharge on insulating surfaces of EUT
±2kV, ±4kV direct discharge & ±2kV, ±4kV, ±8KV air discharger
Test setup
Failure Criteria
Failure Criteria obesrved
10 Single impulses at each test point and for each test voltage
Direct contact discharge
Test voltage Reaction of EUT / result
+2 kV n.r.r.
-2 kV n.r.r.
+4 kV n.r.r.
-4 kV n.r.r.
+6 kV
-6 kV
+8 kV
-8 kV
Remarks: n.r.r = no reaction recognized
Performance Criteria A observed
Issue date:2003-01-10
Contact discharge
to conducted surfaces and to coupling planes
Indirect contact discharge
Reaction of EUT / result
passed
passed
passed
passed
-
-
-
-
n.r.r. passed
n.r.r. passed
n.r.r. passed
n.r.r. passed
-
-
-
-
Page 15 (25)
Air discharge
at insulating surfaces
Reaction of EUT / result
n.r.r. passed
n.r.r. passed
n.r.r. passed
n.r.r. passed
-
-
n.r.r. passed
n.r.r. passed
