HPE Apollo 4200 Gen10 Plus User Manual page 91

power cable and lug kit listed below can only be used with the 1600 W -48 VDC power supply.)
If you are using an input power cord option, the P22173-B21 HPE 1600 W DC PSU power cable kit can be purchased from an authorized
HPE reseller. (The power cable and lug kit listed below can only be used with the 1600 W -48 VDC power supply.)
1600 W -48VDC power cable color codes 1600 W -48VDC power cable color codes
Cable color Cable color Description Description
Black Positive return
Red Negative input voltage
Green/yellow Safety ground
About this task About this task
The DC power supply option kits do not ship with a Power Supply DC cable Kit and may not include a Power Supply Cable Lug kit. The
optional DC Cable kit or the optional DC Cable Lug Kit may be purchased directly from Hewlett Packard Enterprise or an authorized HPE
reseller. For additional information, refer to the power supply QuickSpecs at https://www.hpe.com/info/fsps-qs
WARNING: WARNING:
To reduce the risk of electric shock, fire, and damage to the equipment, you must install this product in
accordance with the following guidelines:
The HPE 1600 W Flex Slot -48 VDC hot-plug power supply is intended only for installation in
Hewlett Packard Enterprise servers located in a restricted access location.
The HPE 1600 W Flex Slot -48 VDC hot-plug power supply is not intended for direct connection to
the DC supply branch circuit. Only connect this power supply to a power distribution unit (PDU) that
provides an independent overcurrent-protected output for each DC power supply. Each output
overcurrent-protected device in the PDU must be suitable for interrupting fault current available
from the DC power source and must be rated no more than 45 A.
The PDU output must have a shut-off switch or a circuit breaker to disconnect power for each power
supply. To completely remove power from the power supply, disconnect power at the PDU. The end
product may have multiple power supplies. To remove all power from the product, disconnect the
power for each power supply.
In accordance with applicable national requirements for Information Technology Equipment and
Telecommunications Equipment, this power supply only connects to DC power sources that are
classified as SELV or TNV. Generally, these requirements are based on the International Standard for
Information Technology Equipment, IEC 60950-1/IEC 62368-1. In accordance with local and regional
electric codes and regulations, the DC source must have one pole (Neutral/Return) reliably connected
to earth ground.
You must connect the power supply ground screw located on the front of the power supply to a
suitable ground (earth) terminal. In accordance with local and regional electric codes and regulations,
this terminal must be connected to a suitable building ground (earth) terminal. Do not rely on the
rack or cabinet chassis to provide adequate ground (earth) continuity.
Procedure Procedure
1. If necessary, remove the power supply blank.
https://www.hpe.com/info/fsps-qs.
HPE Apollo 4200 Gen10 Plus Server User Guide 91
