Item Description Item Description
1 Capacity
2 Rank
3 Data width on DRAM
4 Memory generation
5 Maximum memory speed
6 CAS latency
7 DIMM type
System maintenance switch descriptions System maintenance switch descriptions
Example Example
8 GB
16 GB
32 GB
64 GB
128 GB
256 GB
1R = Single rank
2R = Dual rank
4R = Quad rank
8R = Octal rank
x4 = 4-bit
x8 = 8-bit
PC4 = DDR4
3200 MT/s
AA = CAS 22-22-22
AA = CAS 26-22-22 (for 3DS LRDIMM)
E = Unbuffered ECC (UDIMM)
R = RDIMM (registered)
L = LRDIMM (load reduced)
