5-14
Troubleshooting and Options for the Docking Station II
4.
Locate the hard disk drive signal cable and disconnect the end attached to the
hard disk drive. Next, disconnect the end attached to the interface board. Remove
the hard disk drive signal cable.
HDD Signal
Connectors
Figure Section 5-16 Signal Cable(s) Removal
FDD Signal
Connectors
