For more information on using multiple configurations in Windows 95, search
for "hardware profiles" in Windows Help.

Installing PC (PCMCIA) Cards

If you plan to use a PC card while your NEC Versa is in the NEC Versa Dock, it
is recommended that you dock the system before installing the card. The IDE
controller inside the NEC Versa Dock uses IRQ11 and if the card is installed
before docking it could cause a resource conflict with the system.

Connecting External Devices

Review the following sections for instructions on connecting external devices to
the NEC Versa Dock.
Serial Device
The NEC Versa Dock is equipped with an industry standard 9-pin RS-232C
serial port. Use this port to install a serial device such as a printer or an external
modem.
When you connect a printer, be sure to install the
appropriate printer driver through the Windows Control
Panel.
Follow these steps to connect a serial device to your NEC Versa Dock.
1. Check that both the NEC Versa and the device power are off.
2. Align and connect the 9-pin connector to the serial port on the NEC Versa
Dock.
3. Secure the connection with the screws provided on the cable.
4. Align and connect the other end of the cable to the appropriate port on the
device, if necessary. Secure the connections with the screws provided, if
necessary.
2-40 System Configuration and Setup
