The following procedure describes how to use the AudioRack or AudioRack
32 software to record sound into a file on the NEC Versa. (You can also use
the Microsoft Sound Recorder. Look in Accessories for the Multimedia
group and select "Sound Recorder.")
To record from an external device such as a portable tape player, you
1.
need a cable with audio jacks on both ends. Set up your hardware as
follows:
T
Connect one end of the audio cable to the Line Out jack on the exter-
nal device. (On some devices, you can record from the headphones
port.)
T
Connect the other end of the cable to the Line In port on the NEC
Versa. (You can also use the microphone port to record monaural
sound.)
To record from the internal CD-ROM or from file, start with step 2.
From Window for Workgroups, open the AudioRack program group and
2.
start the AudioRack program (in Windows 95 and Windows NT, this is
called AudioRack32). The AudioRack control panel (similar to the fol-
lowing) appears on your screen.
The control panel provides six different panels for Windows 95 and
Windows NT. Windows for Workgroups provides five panels. (If your
control panel offers fewer, simply press the device buttons next to the
power button. The missing panels will appear.) These panels include the
following:
T
The top three (Windows for Workgroups) or top four control power
(power panel), stereo mixing (3D-Stereo panel) (Windows 95 and
Windows NT), volume control (Mixer panel), and recording (DAT
panel).
T
The lower two panels control your input sources, including:
3. Prepare for your recording as follows:
5-2 Using Multimedia
MIDI panel for recording from existing MIDI or RMI files.
CD panel for recording from the CD-ROM reader.
