NOTE
ROM reader.

Card Bus/PC Card Slots

Your NEC Versa notebook integrates two card bus slots for inserting two
Type II PC cards. You can also insert one Type III PC card. The 32 bit card
bus also has zoomed video support in the bottom slot only.
NOTE
also accepts new CardBus cards.
Using the system's CardBus slots, you can add optional PC cards and con-
nect external devices to your NEC Versa. These devices include peripheral
devices, such as modems, LAN cards, and storage cards. For details on how
to obtain these options, see the online NEC Versa Tools Catalog. Also, for
more information on PC card technology, see the online Advanced Topics in
the NEC Versa 6060 Help Center.

Inserting a PC Card

To insert a PC card, open the slot cover and follow these steps.
NOTE
when using PC cards, especially if using the card in a warm envi-
ronment or over an extended period of time. Failure to do so may
cause some cards to overheat and damage the card or the system.
Align the card so that the 68-pin connector points towards the slot.
1.
2. Slide the card into either slot. A low tone followed by a high tone lets you
know that the card is fully inserted and recognized. (If you decide to turn
off the sound through Setup, no sound is emitted.)
4-14 Using Your NEC Versa
Some CDs vibrate when playing. This does not effect the CD-
This 32-bit CardBus structure is backward compatible, but
We recommend that you keep the PC card slot cover open
