SET COMMUNICATION:
This section defines the fundamental communication parameters of two buses, PROFIBUS and
Modbus TCP.
By pressing the "Set Communication" button from the main window for SW67564 (Fig. 2) the window
"Set Communication" appears (Fig. 3).
The window is divided in three sections, one for selecting the device used, one for the Modbus TCP
(Ethernet) and one for the PROFIBUS.
In the section "Select Device" is possible to select the type of converter used:
HD67564-A1 ("Device from May 2014 (with Dip-Switch)");
HD67564M ("Device till April 2014 (with Jumper)").
The means of the fields for "Modbus TCP
In the field "IP ADDRESS", the IP address of the Modbus TCP side is defined;
In the field "SUBNET Mask", SubNet Mask of the Modbus TCP network is defined;
If the field "GATEWAY" is checked, insert the default gateway that you want to use. This feature
can be enabled or disabled pressing the Check Box field. This feature is used for going out of the
net (only for HD67564-A1);
In the field "Port", the number of the port of the Modbus TCP side is defined (only for
HD67564M);
In the "TimeOut (ms)" define the maximum time that the converter waits for the answer from
the slave interrogated;
In the field "Cyclic Delay
If the field "Write Only When Data
writing requests only when the data on PROFIBUS side change (only for HD67564M);
If the field "Don't Disconnect the
response it does not disconnect the opened socket; otherwise for every request the Converter
opens the socket and when it receives the TCP response it closes it (only for HD67564M).
ADFweb.com Srl – IT31010 – Mareno – Treviso
Master" are:
(ms)" the delay between two Modbus requests is defined;
Change" is checked, the converter sends the Modbus
Socket" is checked, when the Converter receives the TCP
User Manual PROFIBUS Slave / Modbus TCP Master
Document code: MN67564_ENG
Figure 3: "Set Communication" window
