4.3.4 Hardware Interface Level Services
Service drivers are provided as useful subroutines available to any driver. Currently the hardware
interface level has only one service, the tracking sprite, V_STRACK. (For more information on
sprites see Section 6).
4.3.4.1 V_STRACK Driver (BP
=
OOOSAH)
V_STRACK is called by the logical GID drivers to move the graphics cursor (sprite) on the display
screen. V_STRACK provides functions that allow the parameters of the sprite to be defined, and
move the sprite around the display.
A summary of the V_STRACK function codes is provided in table 4.20.
Table 4.20
~
V_STRACK Driver Function Code
Summary
Vector Func. Function
Address
Value Equate Definition
OOSAH
V_STRACK
Sprite control
OOSAH
02
F_SYSTEM
System functions
OOSAH
02/00
SF_INIT
Initialize driver
OOSAH
02/02
SF_START
Start driver
OOSAH
04 F_TRACLINIT Sets tracking to default state
OOSAH
06 F_TRACLON Enables tracking
OOSAH
08
F_TRACLOFF Disables tracking
OOSAH
OA F_DEF_MASKS
Define sprite masks
OOSAH
OC F_S ET_LI M ITS----><
Set max/min horizontal values
OOSAH
DE
F_SET_LI M ITS_Y
Set max/min vertical values
OOSAH
10
F_PUT_SPRITE
Display sprite
OOSAH
12
F_REMOVE_SPRITE
Remove sprite from display
Input System and HP-HIL 129
